Item TRENDnet TV-IP318PI Indoor / Outdoor 8MP 4K H.265 WDR PoE IR Bullet Network Camera
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $165.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Note Currently out of stock
Available Quantity 0
UPC 710931111194
SKU mingleTV-IP318PI
Item TRENDnet TV-IP420P Indoor/ Outdoor 3 MP Motorized PTZ Dome Network Camera
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $399.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Note Currently out of stock
Available Quantity 0
UPC 710931110890
SKU mingleTV-IP420P
Item TRENDnet TI-M6024 60W Single Output Industrial DIN-Rail Power Supply
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $52.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TI-M6024
- Features:
- Industrial power supply with integrated DIN-rail mount
- Provides up to 60 Watts of power (24 V, 2.5 A)
- Universal AC input
- Short circuit/overload/over voltage protection
- UL 508 approved
- 100% full load burn-in test
- Extreme -20 to 70 C (-4 to 158 F) operating temperature range
- Special Features:
- DC OK relay contact
- Short circuit/overload/over voltage protection
- Protection type - shut down and repower
- Interface:
- Input:100-240 V AC, 50/60 Hz, 1.8 A 120-370 V DC
- Output: 60 Watts, 24 V, 2.5A
- DIN-rail: TS-35/7.5 or 15
- Housing:
- Metal case
- DIN-rail mount
- LED indicator confirms power to the unit
- MTBF: 2,992,000 hours
- Certifications: CE, UL 508, UL 60950-1, CB 60950-1, TUV EN60950-1, Class I, Div. 2 hazardous locations T4
- Dimensions: 1.6 x 3.9 x 3.5 inch / 40.0 x 100.0 x 90.0 mm
- Weight: 10.6 oz / 0.3 kg
Note Currently out of stock
Available Quantity 0
UPC 710931160376
SKU mingleTI-M6024
Item TRENDnet TEG-MGBS10 (Version 2.0R) Mini-GBIC Single-Mode LC Module
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $38.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TN-MGBS10
- Features:
- Compliant with IEEE 802.3z Gigabit Ethernet and Fiber Channel Standards
- Industry standard SFP package
- Duplex LC connector
- 1.0625Gbps Fiber Channel Compliant
- 1.25Gbps Gigabit Ethernet Compliant
- Single 3.3V Power Supply Voltage
- Wavelength: 1310nm
- Media: SMF (Single Mode Fiber)
- Power Budget: -9 ~ -3dBm
- Sensitivity: -20
- Power: 11dBm
- Distance: 10km
Application: Switch to Switch Interface, High Speed I/O for File Server, Distributed Multi-Processing
Note Currently out of stock
Available Quantity 0
UPC 710931501612
SKU mingleTEG-MGBS10
Item TRENDnet TEG-MGBSX (Version 2.0R) Mini-GBIC Multi-Mode SX Module
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $34.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEG-MGBSX
- Features:
- Compliant with IEEE 802.3z Gigabit Ethernet and Fiber Channel Standards
- Industry standard SFP package
- Duplex LC connector
- 1.0625Gbps Fiber Channel Compliant
- 1.25Gbps Gigabit Ethernet Compliant
- Single 3.3V Power Supply Voltage
- Wavelength: 850nm
- Media: MMF (Multi-Mode Fiber)
- Power Budget: -9 ~ -3dBm
- Sensitivity: -18
- Power: 9dBm
- Distance: 550m
Application: Switch to Switch Interface, High Speed I/O for File Server, Distributed Multi-Processing
Note Currently out of stock
Available Quantity 0
UPC 710931501605
SKU mingleTEG-MGBSX
Item TRENDnet TC-P16C5E (Version 1.0) 16-Port Cat5/5e Unshielded Patch Panel
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $34.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-P16C5E
- Features
- Gigabit ready rack mount 16-port panel
- Cat6 patch panels deliver a steady 350Mhz connection to copper Gigabit switches
- Ideal solution for Ethernet, Fast Ethernet and Gigabit applications
- Use with TRENDnet TC-PDT Punch Down Tool
- CAT5e grade 110 style connectors with color-coded labeling for T568A and 568B wiring schemes
- 1000Base-T Gigabit Copper Ethernet ready
- Backward compatible with CAT 3, 4 and 5 cabling
- Meets EIA/TIA 568A and ISO/IEC 11801
Note Currently out of stock
Available Quantity 0
UPC 710931401110
SKU mingleTC-P16C5E
Item TRENDnet TPE-224WS 28-Port Gigabit Web Smart PoE Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $305.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TPE-224WS
- Features:
- IEEE 802.3af Power over Ethernet (PoE) Standard Compliant
- Supports PoE Power upto 15.4 watts for each PoE port
- Supports PoE Power maximum upto 170 watts for all PoE ports
- Supports PoE Powered Device (PD) classification identify
- Full Wire-Speed Non-Blocking Reception and Transmission
- Store and Forward Switching Method
- 1Mbits RAM Data Buffer and 8K entries MAC Address Table
- Extensive Diagnostic LEDs on the Front Panel
- Proprietary Windows Based Management/Monitoring Utility (similar to SNMP Trap)
- Supports 802.1Q VLAN (VID 1 ~ 4094), Trunking and Port Mirroring
- Port Setting Function, Users can set each Ports Availability, Speed, Duplex Mode, and Flow Control
- Easy configuration via Web browser
- Standard 19 (1U) Rack-Mount size (kit included)
- Network Standard: IEEE 802.3 10Base-T; IEEE802.3u 100Base-TX; IEEE 802.3ab 1000base-T; IEEE 802.3af Power over Ethernet
- Port: 24x 10/100Mbps Auto-MDIX PoE Ports; 4x 10/100/1000Mbps Auto-MDIX Gigabit Ports; 2x 1000Base-SX/LX Mini GBIC ports for optional Mini-GBIC modules
- Data Transfer Rate:
- Ethernet: 10/20Mbps (half/full duplex)
- Fast Ethernet: 100/200Mbps (half/full duplex)
- Gigabit: 2000Mbps (full duplex)
- Network Media:
- 10BASET: 2-pair UTP Cat. 3, 4, 5; Upto 100m
- 100BASE-TX: 2-pair UTP Cat. 5, 5E; Upto 100m
- 1000BASE-T: 4-pair UTP Cat. 5, 5E, 6; Upto 100m
- PoE: 4-pair UTP Cat. 5; Upto 100m
- Protocol/Topology: CSMA/CD; Star
- RAM Buffer/Filtering: 1Mbits / 8K entry per device
- PoE (Power over Ethernet):
- Upto 15.4W per port; Max 170W for all PoE ports
- PD classification Identify; Manual setting for PoE power limitation
- Supports PoE priority setting; PoE over current protection
- PoE circuit sorting protection
- PoE power on RJ-45 pin 3,6 for Power+ and pin 1,2 for Power
- Diagnostic LEDs: Per Unit - Power, System; Per Port - Link/Activity, Speed; PoE - PoE Status
- Power: 100~240VAC 50/60Hz, Internal Universal Switching Power Supply
- Power Consumption (170W max for PoE): 26.5W (no PD Device connected); 196.5W max (11x15.4 watts PoE Device connected)
- Certification: FCC, CE
- Dimensions: 17.3 x 1.73 x 12 inch / 440 x 44 x 310 mm
- Weight: 9.75 lbs / 4.43 kg
Note Currently out of stock
Available Quantity 0
UPC 710931505047
SKU mingleTPE-224WS
Item TRENDnet TPE-TG81G 8-Port Gigabit GREENnet PoE+ Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $154.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TPE-TG81G
- Features:
- 8x Gigabit PoE+ ports (up to 30 watts per PoE+ port)
- Internal power supply
- Up to 30 W per port with 105 W total power budget
- Reduces equipment cost by delivering data and power over existing network cables
- 16 Gbps switching capacity
- Sturdy rack mountable metal case
- Up to 75% GREENnet power savings
- Standard:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3at Power over Ethernet (PoE+)
- IEEE 802.3af Power over Ethernet (PoE)
- IEEE 802.3x Flow Control
- IEEE 802.3az Energy Efficient Ethernet
- Ports: 8x Gigabit Auto-MDIX PoE / PoE+ RJ-45 Ports
- Data Transfer Rate:
- Ethernet: 10/20 Mbps (Half / Full Duplex)
- Fast Ethernet: 100/200 Mbps (Half / Full Duplex)
- Gigabit: 2000 Mbps (Full Duplex)
- Forwarding Rate: Gigabit / 1,488,000 pps, 100 Mbps / 148,800 pps, 10 Mbps / 14,880 pps
- Data RAM Buffer: 96 Kbytes
- Address Table: 2 K MAC entries
- Switch Fabric: 16 Gbps
- Power: 90-260 V, 50/60 Hz, 1 A
- Diagnostic LEDs: Power, PoE, Link / Activity
- Power Consumption:
- Min: 8 Watts (standby)
- Max: 122 Watts
- PoE Max: 105 Watts (7 x 15 watts PoE devices connected or 3 x 30 Watts PoE+ devices connected)
- Power over Ethernet:
- Up to 15.4 watts for PoE
- Up to 30 watts for PoE+
- PoE: pin 3,6 for power+ and pin 1,2 for power- (mode A)
- Certifications: CE, FCC
- Dimensions: 10.5 x 6.3 x 1.7 inch / 266.0 x 160.0 x 44.0 mm
- Weight: 3.0 lbs / 1.36 kg
- Package Contents:
- TPE-TG81g
- Quick Installation Guide
- Power Cord
- Rack mount brackets
Note Currently out of stock
Available Quantity 0
UPC 710931160055
SKU mingleTPE-TG81G
Item TRENDnet TI-PG102 10-Port Industrial Gigabit PoE+ DIN-Rail Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $390.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Note Currently out of stock
Available Quantity 0
UPC 710931160932
SKU mingleTI-PG102
Item TRENDnet TI-PG541I 6-Port Hardened Industrial Gigabit PoE+ Layer 2 Managed DIN-Rail Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $332.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Note Currently out of stock
Available Quantity 0
UPC 710931160581
SKU mingleTI-PG541I
Item TRENDnet TI-S12024 120W 24V 5A AC to DC DIN-Rail Power Supply w/ PFC Function
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $100.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TI-S12024
- Features:
- Industrial power supply with integrated DIN-rail mount
- Provides up to 120W of power (24V DC, 5A)
- High efficiency 91% and low power dissipation
- 150% peak load capability
- Built-in active Power Factor Controller (PF > 0.93)
- Cooling by free air convection
- Protections - Short circuit, overload, over voltage, over temperature
- UL 508 approved
- Built-in DC OK relay contact
- 100% full load burn-in test
- Special Features:
- DC OK relay contact
- 150% peak load capacity
- Short circuit/overload/over voltage/over temperature protection
- Protection type - shutdown and repower
- Interface:
- Input: 88 - 264V AC, 57 - 63Hz, 1.8A 124 - 370V DC
- Output: 120 W, 24 V, 5A
- DIN-rail: TS-35/7.5 or 15
- Housing:
- DIN-rail mount
- Power LED indicator
- Operating Temperature: -25 ~ 70 C (-13 ~ 158 F)
- Operating Humidity: Max. 95% non-condensing
- MTBF: 2,899,000 hours
- Certifications: CE, UL 508CB 60950-1, TUV EN60950-1
- Dimensions: 1.6 x 4.9 x 4.5 inch / 40.0 x 125.0 x 114.0 mm
- Weight: 23.6 oz / 670.0 g
- Package Contents: TI-S12024 (Mean Well SDR-120-24)
Note Currently out of stock
Available Quantity 0
UPC 710931161434
SKU mingleTI-S12024
Item TRENDnet TI-S24048 240W Single Output Industrial DIN-Rail Power Supply
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $173.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TI-S24048
- Features:
- Industrial power supply with integrated DIN-rail mount
- Provides up to 240 Watts of power (48 V, 5 A)
- Built-in active PFC (PF > 0.93)
- Short circuit/overload/over voltage/over temperature protection
- High efficiency (94%) design
- UL 508 approved
- 100 % full load burn-in test
- Extreme -25 to 70 C (-13 to 158 F) operating temperature range
- Special Features:
- DC OK relay contact
- 150% peak load capacity
- Short circuit/overload/over voltage/over temperature protection
- Protection type: shut down and repower
- Interface:
- Input:100-240 V AC, 50/60 Hz, 1.8 A 125-370 V DC
- Output: 240 Watts, 48 V, 5A
- DIN-rail: TS-35/7.5 or 15
- Housing:
- Metal case
- DIN-rail mount
- LED indicator confirms power to the unit
- MTBF: 1,693,000 hours
- Certifications: CE, UL 508CB 60950-1, TUV EN60950-1
- Dimensions: 1.6 x 4.9 x 4.5 inch / 40.0 x 125.0 x 114.0 mm
- Weight: 2.3 lbs / 1.03 kg
Note Currently out of stock
Available Quantity 0
UPC 710931160390
SKU mingleTI-S24048
Item TRENDnet TEG-S24D 24-Port Gigabit GREENnet Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $92.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TEG-S24D
- Features:
- Plug and Play - Simply power up the switch and plug in connected devices
- QoS Prioritization - MAC level IEEE 802.1p Quality of Service (QoS) traffic prioritization pass-through support
- Jumbo Frame - Sends larger packets, or Jumbo Frames (up to 9 KB), for increased performance
- LED Indicators - LED indicators convey port status
- Fanless - Fanless design lowers energy consumption and eliminates operating noise
- Energy Savings - Embedded GREENnet technology reduces power consumption
- Standards:
- IEEE 802.1p
- IEEE 802.3/ 3u/ 3x/ 3ab/ 3az
- Data Transfer Rates:
- Ethernet: 10Mbps/20Mbps (half/full-duplex)
- Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
- Gigabit Ethernet: 2000Mbps (full-duplex)
- Performance:
- Switch Fabric: 48 Gbps
- Ram Buffer: 4 MB
- MAC Address Table: 8K entries
- Jumbo Frames: 9 KB
- Special Feature:
- Supporting 802.1p QoS packet prioritization
- Up to 40% GREENnet energy savings
- Interface: 24x Gigabit ports, LED indicators, Power Port
- MTBF: 2,344,449 hours
- Power Consumption: 12 Watts (max)
- Power:
- Input: 100 - 240 V AC, 50/60 Hz, 0.8 A
- Output: 12 V DC, 1.5 A
- Certifications: CE, FCC
- Dimensions: 9.9 x 6.2 x 1.9 inch / 251.0 x 158.0 x 48.0 mm
- Weight: 3.5 lbs / 1.6 kg
- Package Contents: TEG-S24D, Quick Installation Guide, Power adapter (12 V DC, 1.5 A)
Note Currently out of stock
Available Quantity 0
UPC 710931140132
SKU mingleTEG-S24D
Item TRENDnet TW100-S4W1CA (Version G1.0R) 4-Port Broadband Router
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $30.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TW100-S4W1CA
- Features
- Supports Cable/DSL Modem with Dynamic IP, Fixed IP, PPPoE and PPTP Connection Types
- Provides NAT (Network Address Port Translation) Firewall
- Supports Virtual Servers (Port Forwarding) and DMZ
- Supports Client Filtering by Date/Time and Special Applications Filter (10 Entries)
- Supports MAC Address Control to Allow or Deny Access (32 Entries)
- Supports DNS (Domain Name System) Account for Server Mapping and Dynamic DNS Service
- Supports IPSec and PPTP VPN Pass-Through (when each VPN client connects to a different VPN endpoint)
- Supports UPnP (Universal Plug & Play)
- Easy Web Browser Configuration and Remote Management
- Flash Memory for Firmware Upgrade and Save/Restore Router Configuration
- Multiple VPN Pass-through sessions for IPSec, PPTP and L2TP
- Standards: EEE 802.3 10Base-T Ethernet; IEEE 802.3u 100Base-TX Fast Ethernet
- Protocols: TCP/IP, NAT, PPPoE, UPnP, HTTP, DHCP Server/Client, SNTP
- WAN: 1x 10/100Mbps port (Internet)
- LAN: 4x 10/100Mbps Auto-MDIX ports
- Router:
- Connection Type: Dynamic IP, Static (Fixed) IP, PPPoE, PPTP
- Firewall: NAT, IP / MAC Address Filter, Domain / URL Blocking, Scheduling, UPnP
- VPN: IPSec, PPTP pass-through
- Management: Web Browser Configuration & Remote Management
LED Indicators: Power, WAN, Link/Act, LAN ports
Certifications: FCC, CE
Dimensions (WxLxH): 6 x 4.3 x 1.3 inch / 154 x 110 x 33 mm
Weight: 8 oz / 225 g
Note Currently out of stock
Available Quantity 0
UPC 710931301144
SKU mingleTW100-S4W1CA
Item TRENDnet TEG-S50ES 5-Port Gigabit Edge Smart Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $38.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TEG-S50ES
- Features:
- 5x Gigabit ports
- Easy to use web-based management interface
- Supports LACP, RSTP, VLAN, QoS, and IGMP Snooping
- Bandwidth control per port
- 10Gbps switching capacity
- IEEE 802.1p CoS with queue scheduling support
- Compact fanless design
- Wall mountable metal housing
- Enable/disable 802.3az Power Saving
- Wall mountable
- Standards:
- IEEE 802.1d
- IEEE 802.1w
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3ad
- IEEE 802.3z
- Device Interface:
- 5x Gigabit Ports
- LED indicators
- Reset button
- Data Transfer Rate:
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit Ethernet: 2000Mbps (full duplex)
- Performance:
- Switch Fabric: 10 Gbps
- RAM Buffer: 125KB
- MAC Address Table: 2K entries
- Jumbo Frames: 9KB
- Forwarding Rates: 7.44 Mpps (64-byte packet size)
- Management:
- HTTP Web based GUI
- SNMP v1, v2c
- Cable diagnostic test
- Backup/Restore Configuration
- Upload Firmware
- Spanning Tree:
- IEEE 802.1d STP (spanning tree protocol)
- IEEE 802.1w RSTP (rapid spanning tree protocol)
- Link Aggregation: 802.3ad Dynamic LACP (1 group)
- Quality of Service (QoS):
- Port-based QoS
- 802.1p Class of Service (CoS)
- Bandwidth Control/Rate Limiting per port (Min. Limit - 8Kbps)
- Queue Scheduling - Strict Priority (SP), Weighted Fair Queueing (WFQ)
- VLAN:
- Port-based VLAN
- 802.1Q Tagged VLAN
- Up to 32 VLAN groups, ID Range 1-4094
- Private VLAN
- Asymmetric VLAN
- Voice VLAN (5 user defined OUIs)
- Multicast:
- IGMP Snooping v1/2/3
- Block unknown multicast source
- Up to 32 multicast groups
- Port Mirror:
- Storm Control:
- Broadcast (Min. Limit -8Kbps)
- Multicast (Min. Limit - 8Kbps)
- Loopback Detection
- Power:
- Input: 100 - 240V AC, 50/60Hz, 0.2A
- Output: 5V DC, 1A external power adapter
- Max consumption: 3.42W
- Fan / Acoustics: Fanless design
- MTBF: 1,633,047 hours
- Certifications: CE, FCC
- Dimensions: 3.95 x 3.22 x 1.10 inch / 100.5 x 82.0 x 28.0 mm
- Weight: 7.9 lbs / 224.0 g
- Package Contents: TEG-S50ES, Quick Installation Guide, Power adapter (5V DC, 1A)
Note Currently out of stock
Available Quantity 0
UPC 710931140491
SKU mingleTEG-S50ES
Item TRENDnet TEG-S5g (Version 1.0R) 5-Port Gigabit GREENnet Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEG-S5G
- Features
- 5x 10/100/1000Mbps Auto-Negotiation, Auto-MDIX Gigabit Ethernet Ports
- Store-and-Forward switching architecture with non-blocking wire-speed performance
- IEEE 802.3x Flow Control for full-duplex mode
- Back pressure Flow Control for half-duplex mode
- Integrated address look-up engine with 1K absolute MAC address table and 104KBytes RAM data buffering
- Operates and maximizes packet filtering and forwarding rate
- Jumbo Frame support up to 9216bytes
- Diagnostic LEDs and Plug & Play
- Standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3x Flow Control
- Network Media
- Ethernet: Cat. 3,4,5, upto 100m
- Fast Ethernet: Cat. 5, upto 100m
- Gigabit Ethernet: Cat. 5, 5e, 6, upto 100m
- Data Rate
- Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)
- Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)
- Gigabit Ethernet: 2000Mbps (Full-Duplex)
- Protocol / Topology: CSMA/CD, Star
- Power Consumption: 3w (max)
- Switch Fabric: 10Gbps Forwarding Capacity
- Interface: 5x 10/100/1000Mbps Auto-MDIX RJ-45 Ports
- Data RAM Buffer: 104KBytes
- Filtering Table: 1K entries
- Certifications: FCC, CE
- Diagnostic LED: Power, Link/ACT, 100Mbps, 1000Mbps
- Power Adapter: 5V DC, 2.5A external power adapter
- Dimensions: 5.9 x 4.1 x 1.3 inch/ 150 x 105 x 33 mm
- Weight: 8 oz/ 225g
Note Currently out of stock
Available Quantity 0
UPC 710931610123
SKU mingleTEG-S5G
Item TRENDnet TEG-S80ES 8-Port Gigabit Edge Smart Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $47.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TEG-S80ES
- Features:
- 8x Gigabit ports
- Easy to use web-based management interface
- Supports LACP, RSTP, VLAN, QoS, and IGMP Snooping
- Voice VLAN for VoIP applications
- Bandwidth control per port
- 16Gbps switching capacity
- IEEE 802.1p CoS with queue scheduling support
- Compact fanless design
- Wall mountable metal housing
- Enable/disable 802.3az Power Saving
- Wall mountable
- Standards:
- IEEE 802.1d
- IEEE 802.1w
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3ad
- IEEE 802.3z
- Ports:
- 8x Gigabit Ports
- LED indicators
- Reset button
- Data Transfer Rate:
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit Ethernet: 2000Mbps (full duplex)
- Performance:
- Switch Fabric: 16 Gbps
- RAM buffer: 192KB
- MAC Address Table: 4K entries
- Jumbo Frames: 9KB
- Forwarding rate: 11.9Mpps (64-byte packet size)
- Management:
- HTTP Web based GUI
- SNMP v1, v2c
- Cable diagnostic test
- Backup/Restore Configuration
- Upload Firmware
- Spanning Tree:
- IEEE 802.1d STP (spanning tree protocol)
- IEEE 802.1w RSTP (rapid spanning tree protocol)
- Link Aggregation: 802.3ad Dynamic LACP (up to 2 groups)
- Quality of Service (QoS):
- Port-based QoS
- 802.1p Class of Service (CoS)
- Bandwidth Control/Rate Limiting per port (Min. Limit - 8Kbps)
- Queue Scheduling - Strict Priority (SP), Weighted Fair Queueing (WFQ)
- VLAN:
- Port-based VLAN
- 802.1Q Tagged VLAN
- Up to 32 VLAN groups, ID Range 1-4094
- Private VLAN
- Asymmetric VLAN
- Voice VLAN (5 user defined OUIs)
- Multicast:
- IGMP Snooping v1/2/3
- Block unknown multicast source
- Up to 32 multicast groups
- Port Mirror:
- Storm Control:
- Broadcast (Min. Limit - 8Kbps)
- Multicast (Min. Limit - 8Kbps)
- Loopback Detection
- Power:
- Input: 100 - 240V AC, 50/60Hz, 0.2A
- Output: 5V DC, 1A external power adapter
- Max consumption: 4.94W
- Fan / Acoustics: Fanless design
- MTBF: 1,525,460 hours
- Certifications: CE, FCC
- Dimensions: 5.70 x 3.22 x 1.10 inch / 145.0 x 82.0 x 28.0 mm
- Weight: 11.18 lbs / 317.0 g
- Package Contents: TEG-S80ES, Quick Installation Guide, Power adapter (5V DC, 1A)
Note Currently out of stock
Available Quantity 0
UPC 710931140477
SKU mingleTEG-S80ES
Item TRENDnet TI-SG104 Industrial Gigabit UPoE Splitter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $118.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TI-SG104
- Features:
- Power a non-PoE device up to 100m (328 ft.) away from PSE
- Splits a gigabit PoE signal into separate power and data sources
- A single Ultra PoE source can power up to two devices
- Adjustable voltage output supports 12V, 16V, 24V or 48V devices
- For best performance pair with UPoE switches or injectors
- Save on installation and equipment cost
- Full Duplex Gigabit speeds
- IEEE 802.3bt compatible
- Standards: IEEE 802.3/ 3u/ 3ab/ 3af/ 3at/ 3bt compatible
- Device Interface: 1x Gigabit port, 1x Gigabit Ultra PoE in port, 4-pin removable terminal block (dual DC output), Adjustable output power DIP switch (48V, 24V, 16V, 12V), LED indicator, DIN-Rail mount, Wall mount, Grounding point
- Data Transfer Rate:
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
- Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
- Gigabit: 2000Mbps (full duplex)
- Special Features:
- Hardened components rated for extreme temperatures
- Dual DC power output
- Auto-Negotiation
- ESD 4kV and Surge 2kV protection
- Power:
- Input: 15.4W/30W/60W/95W PoE power
- Max. Consumption: 7W (splitter only)
- Max. Combined DC Output: 48V (1.25A), 24V (2.3A), 16V (2.3A), 12V (2.3A)
- Terminal Block:
- Dual DC power outputs, 4 pin
- Wire range: 0.34mm^2 to 2.5mm^2
- Solid wire (AWG): 12-24/14-22
- Stranded Wire (AWG): 12-24/14-22
- Torque: 5 lb. - In / 0.5Nm / 0.56Nm
- Wire strip length: 7-8mm
- MTBF: 684,452 hours
- Housing:
- IP30 metal case
- DIN-rail mount
- Wall mount
- Grounding point
- 4KV ESD protection
- 2KV surge protection
- Certifications:
- CE
- FCC
- IEC EN60950-1
- Shock (IEC 60068-2-27)
- Freefall (IEC 60068-2-32)
- Vibration (IEC 60068-2-6)
- Dimensions: 4.1 x 3.2 x 1.2 inch / 104.0 x 82.0 x 32.0 mm
- Weight: 6.0 oz / 172.0 g
- Package Contents:
- TI-SG104
- Quick Installation Guide
- Removable terminal block
- DIN-rail and wall mount kit
Note Currently out of stock
Available Quantity 0
UPC 710931161380
SKU mingleTI-SG104
Item TRENDnet TBW-107UB (Version 1.0R) Micro-Bluetooth USB Adapter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $20.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TBW-107UB
- Features
- Connect Bluetooth-enabled devices such as printers, headsets, audio/video devices and mobile phones
- Compliant with Class II Bluetooth V2.1+ compliant
- Enhanced Data Rate (EDR) support
- Bluetooth IVT software technology
- Adaptive Frequency Hopping (AFH) support
- Enhanced SCO (eSCO) for crisp and clear voice quality
- Compatible with Windows 7/Vista/XP/2000
- Communicates wirelessly up to 10 meters (32.8ft.) (depends on environment)
- Trouble free Plug & Play installation
- Standards:
- Class II Bluetooth v2.1+ EDR, USB 2.0
- Backwards compatible with Bluetooth v1.1, v1.2, v2.0 and USB 1.1
- Antenna: Internal
- Frequency: 2.4 ~ 2.483 GHz
- Data Rate:
- Basic data rate: upto 3Mbps (typical)
- Date Range: upto 10m (32.8 ft.)
- Profile Support:
- DUN (Dial-up Networking)
- FAX Profile, BPP ( Basic Printing Profile)
- LAP (LAN Access Profile)
- SPP (Serial Port Profile)
- GAP (Generic Access Profile)
- HID (Human Interface Device)
- HCRP (Hardcopy Cable Replacement Profile)
- FTP (File Transfer Profile)
- OPP (Object Push Profile)
- A2DP (Advanced Audio Distribution Profile)
- GAVDP (Generic Audio/Video Distribution Profile)
- HSP (Headset Profile)
- PAN (Personal Area Networking)
- BIP (Basic Image Profile)
- SYNC (Synchronization Profile)
- AV (Audio Video)
- GOEP (Generic Object Exchange Profile)
- RF Output Power: -6 ~ 4dBm (typical)
- Encryption 128 bit data encryption
- Receiving Sensitivity: -82dBm (typical)
- Power Consumption:
- Typical: 95mA; idle: 12mA
- Tx max: 136mA @19dBm; Rx max: 45mA
- Emissions: CE, FCC
- Operating System Support: Windows 7(32/64-bit)/Vista(32/64-bit)/XP(32/64-bit)/2000
- Dimensions: 0.75 x 0.47 x 0.22 inch / 19 x 12 x 5.5 mm
- Weight: 0.063 oz / 1.8 g
- RoHS compliant
Note Currently out of stock
Available Quantity 0
UPC 710931503586
SKU mingleTBW-107UB
Item TRENDnet TC-NTUF USB&Firewire Adapter For TC-NT2
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $18.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-NTUF
- USB & Firewire adapter for TC-NT2
Note Currently out of stock
Available Quantity 0
UPC 710931401233
SKU mingleTC-NTUF
Item TRENDnet TC-NT2 Cable Tester
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $49.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TC-NT2
- Power Requirement: One DC 9V battery
- Tone Frequency: 600 ~ 800 Hz.
- Dimensions (appr.): Master Unit: 115 x 68 x 27 mm (4.5 x 2.7 x 1.1 inch)
- Remote Terminator: 118 x 32 x 27 mm (4.6 x 1.3 x 1.1 inch)
- Weight (appr.): Master Unit: 113 gram (4 Oz.) (without battery)
- Remote Terminator: 57 gram (2 Oz.)
- Tests Pin Configuration of 10/100/1000Base-T, 10Base-2 (coax), RJ-11/RJ-12/RJ-45, EIA/TIA-356A/568A/568B, and Token Ring Cables
- Tests USB and IEEE 1394 cables with optional adapters
- Built-in Tone Generator for tracing cable with standard Tone Probe
- Tests the grounding on shielded (screened) cable
- Verifies cable continuity, opens, shorts, and miswires
- Tests cable upto 300 meters
- Auto-Scan or Manual-Scan mode
- Includes Deluxe Carrying Pouch, two RJ45-to-BNC Adapters, and RJ45 Patch Cable
Note Currently out of stock
Available Quantity 0
UPC 710931401011
SKU mingleTC-NT2
Item TRENDnet TC-P08C6 (Version v1.0R) 8-Port Cat6 Unshielded Patch Panel
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $28.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-P08C6
- Features
- 8x 1000Base-T Gigabit RJ-45 ports
- Supports a 250MHz connection
- 10 inch wide patch panel
- Cat.6 color coded labeling for T568A and T568B wiring schemes
- IDC terminal blocks are compatible with 110 and Krone style connectors
- Labels above each port
- Cat. 6 transmission performance compliant with ANSI, TIA, and EIA 568 B.2 standards
- Nylon cable ties and holders included
- Wiring standards: T568A and T568B
- Network Media: Cat. 6
- Mounting Point Retention Strength: 17 lbs / 7.7 kg
- Certifications: CE, FCC
- Dimensions(WxLxH): 1.7 x 10 x 1.2 inch / 44 x 254 x 30 mm
- Weight: 205 g / 7.2 oz
Note Currently out of stock
Available Quantity 0
UPC 710931401349
SKU mingleTC-P08C6
Item TRENDnet TC-P16C6 16-Port CAT6 RJ-45 UTP 19inch Rackmount Patch Panel
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $38.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-P16C6
- 16-Port Unshielded CAT6 Patch Panels
- Meets ANSI/EIA/TIA 568-B.2-1 and ISO/IEC 11801 Standards
- New version 110D IDC type terminal blocks (use 110 or Krone type tool)
- Color-coded labeling for T568A and T568B wiring schemes
- 180° angle type (horizontal)
- 1000Base-T Copper Gigabit Ethernet ready
- Compatible with Cat. 3, 4, 5, 5e, and 6 cabling
- Works perfectly with TC-PDT Punch Down Tool
- UL E157358 listed
Note Currently out of stock
Available Quantity 0
UPC 710931401196
SKU mingleTC-P16C6
Item TRENDnet TC-P24C5E 24-Port CAT5e RJ45 UTP 19inch Rackmount Patch Panel
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $38.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-P24C5E
- CAT5e grade 110 style connectors with color-coded labeling for T568A and 568B wiring schemes
- 1000Base-T Gigabit Copper Ethernet ready
- Backward compatible with CAT 3, 4 and 5 cabling
- Meets EIA/TIA 568A and ISO/IEC 11801
Note Currently out of stock
Available Quantity 0
UPC 710931401127
SKU mingleTC-P24C5E
Item TRENDnet TC-P48C5E 48-Port CAT5e RJ45 UTP 19 inch Rackmount Patch Panel
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $66.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-P48C5E
- 48-Port CAT5e RJ45 UTP 19inch Rackmount Patch Panel
- CAT5e grade 110 style connectors with color-coded labeling for T568A and 568B wiring schemes.
- 1000Base-T Gigabit Copper Ethernet ready.
- Backward compatible with CAT 3, 4 and 5 cabling.
- Meets EIA/TIA 568A and ISO/IEC 11801.
Note Currently out of stock
Available Quantity 0
UPC 710931401134
SKU mingleTC-P48C5E
Item TRENDnet TC-P48C6 (Version 1.0) 48-port Cat6 Unshielded Patch Panel
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $82.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-P48C6
- Features
- Gigabit ready rack mount 48-port panel
- Cat6 patch panels deliver a steady 250Mhz connection to copper Gigabit switches
- Ideal solution for Ethernet, Fast Ethernet and Gigabit applications
- Use with TRENDnet TC-PDT Punch Down Tool
- Meets ANSI/EIA/TIA 568-B.2-1 and ISO/IEC 11801 Standards
- New version 110D IDC type terminal blocks (use 110 or Krone type tool)
- Color-coded labeling for T568A and T568B wiring schemes
- 180° angle type (horizontal)
- 1000Base-T Copper Gigabit Ethernet ready
- Compatible with Cat. 3, 4, 5, 5e, and 6 cabling
- Works perfectly with TC-PDT Punch Down Tool
- Operating temperature: -40° ~ 80° C (-40° ~ 176° F)
- UL E157358 listed
Note Currently out of stock
Available Quantity 0
UPC 710931401219
SKU mingleTC-P48C6
Item TRENDnet TC-PDT Professional Impact Punch Down Tool
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $24.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TC-PDT
- Comfortable shape, easy to handle
- Interchangeable and reversible blades
- Safe storage for spare blade
- Twist and Lock style holder provides fast, easy blade changes and prevents blade pullout
Note Currently out of stock
Available Quantity 0
UPC 710931401103
SKU mingleTC-PDT
Item TRENDnet TEG-S16G 16-Port Gigabit GREENnet Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $85.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEG-S16G
- Features:
- On/off power switch
- Internal power supply reduces clutter
- GREENnet technology reduces electrical power consumption when:
- Ethernet port is not in use
- Connected device is turned off
- Connected device is in power-saving mode
- Based on Ethernet cable length
- IEEE 802.3x Flow Control for full-duplex mode
- Back pressure Flow Control for half-duplex mode
- Store-and-Forward switching architecture with non-blocking wire-speed performance
- Integrated address look-up engine with an 8K MAC address table
- Operates and maximizes packet filtering and forwarding rate
- Rackmount hardware included
- Sturdy metal housing
- Diagnostic LEDs and Plug & Play support
- Standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3x Flow Control
- IEEE 802.3az (draft 2.0)
- Ports: 16x 10/100/1000Mbps Auto-MDIX RJ45 Ports
- Data Transfer Rates:
- Ethernet: 10Mbps/20Mbps (Half/ Full Duplex)
- Fast Ethernet: 100Mbps/200Mbps (Half/ Full Duplex)
- Gigabit Ethernet: 2000Mbps (Full Duplex)
- Switch Fabric: 32Gbps
- Data RAM Buffer: 2MBits
- Filtering Table: 8K entries
- Jumbo Frame Support: Up to 9216Bytes
- Diagnostic LEDs: Power, Link/ACT, 1000M/100M
- Power Consumption: 7.2 Watts (max)
- Power: 100-240V AC, 50/60Hz Internal universal switching power
- Protocol/Topology: CSMA/CD, Star
- Certifications: CE, FCC
- Dimensions: 17.0 x 5.5 x 1.8 inch / 440.0 x 140.0 x 45.0 mm
- Weight: 3.5 lbs / 1.6 kg
Note Currently out of stock
Available Quantity 0
UPC 710931610239
SKU mingleTEG-S16G
Item TRENDnet TEG-S82G 8-Port Gigabit GREENnet Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $29.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEG-S82G
- Features:
- GREENnet technology reduces power consumption when:
- Ethernet port is not in use
- Connected device is turned off
- Connected device is in power-saving mode
- Based on Ethernet cable length
- Store-and-Forward switching architecture with non-blocking wire-speed performance
- IEEE 802.3x Flow Control for full-duplex mode
- Back pressure Flow Control for half-duplex mode
- 8 K absolute MAC address table
- Operates and maximizes packet filtering and forwarding rate
- IEEE 802.3az Energy Efficient Ethernet technology
- Sturdy metal housing
- Plug & Play
- Standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3x Flow Control
- IEEE 802.3az Energy Efficient Ethernet
- Network Media:
- Ethernet: Cat. 5 up to 100 m
- Fast Ethernet: Cat. 5 up to 100 m
- Gigabit Ethernet: Cat. 5, 5e, 6 up to 100 m
- Data Transfer Rates:
- Ethernet: 10Mbps/20Mbps (half/full-duplex)
- Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
- Gigabit Ethernet: 2000Mbps (full-duplex)
- Protocol/Topology: CSMA/CD, Star
- Switch Fabric: 16 Gbps forwarding capacity
- Interface: 8x Gigabit Auto-MDIX RJ-45 Ports
- Data RAM Buffer: 256 KBytes
- Filtering Table: 8 K entries
- Jumbo Frame Support: Up to 9216 Bytes
- Diagnostic LEDs: Power, Link/ACT, 100Mbps/1000Mbps
- Power Consumption: 3.5 Watts (max)
- Power Adapter:
- Input: 100~240V, 50/60Hz, 190mA
- Output: 5V DC, 1A External Power Adapter
- Certifications: FCC, CE
- Dimensions: 5.8 x 3.8 x 1.0 inch / 148.0 x 97.0 x 26.0 mm
- Weight: 13.4 oz / 380.0 g
- Package Contents: TEG-S82G, Multi-Language Quick Installation Guide, Power Adapter (5V DC, 1A)
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 710931140057
SKU mingleTEG-S82G
Item TRENDnet TEW-L102 2.0 m / 6.5 ft Low Loss RP-SMA Male to RP-SMA Female Antenna Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TEW-L102
- Features:
- Extend your wireless antenna up to 2 meters (6.5 ft.)
- Provides optimal placement for your antenna
- Low loss cable with a max signal loss of 1.45 dB
- Compatible with directional and omni-directional RP-SMA antennas
- Wi-Fi compliant with 2.4 GHz & 5 GHz devices
- Connector Type: RP-SMA jack (male) to RP-SMA plug (female)
- Maximum Cable Loss: 1.45 dB
- Cable Length: 2.0 m / 6.5 ft
- Weight: 2.9 oz / 82.0 g
- Package Contents: TEW-L102
Note Currently out of stock
Available Quantity 0
UPC 710931130683
SKU mingleTEW-L102
Item TRENDnet TEW-L106 6.0 m / 19.6 ft Low Loss RP-SMA Male to RP-SMA Female Antenna Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $30.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEW-L106
- Features:
- Extend your wireless antenna up to 6 meters (19.6 ft.)
- Provides optimal placement for your antenna
- Low loss cable with a max signal loss of 3.0 dB
- Compatible with directional and omni-directional RP-SMA antennas
- Wi-Fi compliant with 2.4 GHz & 5 GHz devices
- Connector Type: RP-SMA jack (male) to RP-SMA plug (female)
- Maximum Cable Loss: 3.0 dB
- Cable Length: 6.0 m / 19.6 ft
- Weight: 8.0 oz / 226.0 g
- Package Contents: TEW-L106
Note Currently out of stock
Available Quantity 0
UPC 710931130690
SKU mingleTEW-L106
Item TRENDnet TEW-L202 2 meters LMR200 Reverse SMA to N-Type Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $27.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEW-L202
- Features:
- Wi-Fi Compliant with 2.4GHz 802.11 b/g & 5GHz 802.11a Devices for extending wireless networks
- Reverse SMA Female to N-Type Male Connector
- Optimal placement of your existing Wi-Fi Device permits you to maximize its wireless performance
- Flexible outer conductor allows the tightest bend radius available for any cable of similar size and performance
- Provides flexible Low-loss communication for wireless antenna
- 50dB RF Shielding is 10 dB greater than typical single shielded coax (40 dB)
- Multi-ply bonded outer foil conductor is rated conservatively at > 90 dB
- Weatherproof cable design for outdoors exposure with best materials for UV resistance
- Polyethylene jacketed cable designed for outdoor use
- Easy and quick deployment into a WLAN environment
- Electrical:
- Cut-off Frequency: 39 GHz
- Velocity of Propagation: 83%
- Dielectric Constant: 1.45
- Time Delay: 1.22 nS/ft (4.02 nS/m)
- Impedance: 50 ohms
- Capacitance: 24.5 pF/ft (80.3 pF/m)
- Inductance: 0.061 H/ft (0.20 H/m)
- Shielding Effectiveness: > 90 dB
- DC Resistance: Inner Conductor - 5.36ohms/1000ft (17.6 ohms/km); Outer Conductor - 4.9 ohms/1000ft (16.1 ohms/km)
- Voltage Withstand: 1000 Volts DC
- Jacket Spark: 3000 Volts RMS
- Peak Power: 2.5 KW
- Construction:
- Inner Conductor (Solid BC): 0.044 inch (1.12 mm)
- Dielectric (Foam PE): 0.116 inch (2.95 mm)
- Outer Conductor (Aluminum Tape): 0.121 inch (3.07 mm)
- Over Braid (Tinned Copper ): 0.144 inch (3.66 mm)
- Jacket (PE): 0.195 inch (4.95 mm)
- Mechanical:
- Bend Radius: Installation - 0.5 inch (12.7 mm); Repeated - 2.0 inch (50.8 mm)
- Bending Moment: 0.2 ft-lb (0.27 N-m)
- Weight: 0.022 lb/ft (0.03 kg/m)
- Tensile Strength: 40 lb (18.2 kg)
- Flat Plate Crush: 15 lb/inch (0.27 kg/mm)
Note Currently out of stock
Available Quantity 0
UPC 710931502923
SKU mingleTEW-L202
Item TRENDnet TEW-L208 8 meters LMR200 Reverse SMA to N-Type Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $37.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEW-L208
- Features:
- Wi-Fi Compliant with 2.4GHz 802.11 b/g & 5GHz 802.11a Devices for extending wireless networks
- Reverse SMA Female to N-Type Male Connector.
- Optimal placement of your existing Wi-Fi Device permits you to maximize its wireless performance.
- Flexible outer conductor allows the tightest bend radius available for any cable of similar size and performance
- Provides flexible Low-loss communication for wireless antenna
- 50dB RF Shielding is 10 dB greater than typical single shielded coax (40 dB).
- Multi-ply bonded outer foil conductor is rated conservatively at > 90 dB.
- Weatherproof cable design for outdoors exposure with best materials for UV resistance
- Polyethylene jacketed cable designed for outdoor use
- Easy and quick deployment into a WLAN environment
- Construction:
- Inner Conductor (Solid BC): 0.044 inch / 1.12 mm
- Dielectric (Foam PE): 0.116 inch / 2.95 mm
- Outer Conductor (Aluminum Tape): 0.121 inch / 3.07 mm
- Over Braid (Tinned Copper): 0.144 inch / 3.66 mm
- Jacket (PE): 0.195 inch / 4.95 mm
- Mechanical:
- Bend Radius: Installation: 0.5 inch / 12.7 mm
- Bend Radius: Repeated: 2.0 inch / 50.8 mm
- Bending Moment: 0.2 ft-lb / 0.27 N-m
- Weight: 0.022 lb/ft / 0.03 kg/m
- Tensile Strength: 40 lbs / 18.2 kg
- Flat Plate Crush: 15 lb/inch / 0.27 kg/mm
- Electrical:
- Cut-off Frequency: 39 GHz
- Velocity of Propagation: 83%
- Dielectric Constant: 1.45
- Time Delay: 1.22 nS/ft / 4.02 nS/m
- Impedance: 50 ohms
- Capacitance: 24.5 pF/ft / 80.3 pF/m
- Inductance: 0.061uH/ft / 0.20 uH/m
- Shielding Effectiveness: > 90 dB
- DC Resistance: 5.36ohms/1000ft / 17.6 ohms/km
- Inner Conductor Outer Conductor: 4.9 ohms/1000ft / 16.1 ohms/km
- Voltage Withstand: 1000 Volts DC
- Jacket Spark: 3000 Volts RMS
- Peak Power: 2.5 kW
Note Currently out of stock
Available Quantity 0
UPC 710931502930
SKU mingleTEW-L208
Item TRENDnet TEW-L402 2.0 m / 6.5 ft N-Type Male to N-Type Female Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $32.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TEW-L402
- Features:
- Extend your wireless antenna up to 2 m (6.5 ft.)
- Allows for optimal placement of your antenna
- Compatible with directional and omni-directional N-Type antennas
- Wi-Fi compliant with 2.4GHz & 5GHz devices
- Connector Type: N-Type Male to N-Type Female
- Maximum Cable Loss: 2.1 dB (2.4 - 2.5GHz); 3.0 dB (5.15 - 5.87GHz)
- Cable Length: 2.0 m / 6.5 ft
- Weight: 5.0 oz / 142.0 g
- Package Contents: TEW-L402, Weatherproof Tape
Note Currently out of stock
Available Quantity 0
UPC 710931130713
SKU mingleTEW-L402
Item TRENDnet TEW-L406 (Version V1.0R/ V2.0R) LMR400 N-Type Male to N-Type Female Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $52.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEW-L406
- Features
- Wi-Fi Compliant with 2.4GHz 802.11 b/g & 5GHz 802.11a Devices for extending wireless networks
- N-Type Male to N-Type Female Connector
- Optimal placement of your existing Wi-Fi Device permits you to maximize its wireless performance
- Flexible outer conductor allows the tightest bend radius available for any cable of similar size and performance
- Provides flexible Low-loss communication for wireless antenna
- 50dB RF Shielding is 10 dB greater than typical single shielded coax (40 dB)
- Multi-ply bonded outer foil conductor is rated conservatively at > 90 dB
- Weatherproof cable design for outdoors exposure with best materials for UV resistance
- Polyethylene jacketed cable designed for outdoor use
- Easy and quick deployment into a WLAN environment
- Construction
- Inner Conductor (BCCAI): 0.108 in / 2.74 mm
- Dielectric (Foam PE): 0.285 in./ 7.24 mm
- Outer Conductor (Aluminum Tape): 0.291 in./ 7.39 mm
- Over Braid (Tinned Copper ): 0.320 in. / 8.13 mm
- Jacket (PE): 0.405 in./ 10.29mm
- Mechanical
- Bend Radius(Installation): 1.0 in./ 25.4mm
- Bend Radius: Repeated 4.0 in. / 101.6 mm
- Bending Moment: 0.5 ft-lb / 0.68 N-m
- Tensile Strength: 160 lb / 72.6 kg
- Flat Plate Crush: 40 lb/in./ 0.71 kg/mm
- Weight: 0.068 lb/ft / 0.10 kg/m
- Cut-off Frequency: 16.2 GHz
- Velocity of Propagation: 85%
- Dielectric Constant: 1.38
- Time Delay: 1.20 nS/ft / 3.92 nS/m
- Impedance: 50 ohms
- Capacitance: 23.9 pF/ft / 78.4 pF/m
- Inductance: 0.060 uH/ft / 0.20 uH/m
- Shielding Effectiveness: > 90 dB
- DC Resistance
- Inner Conductor: 1.39 ohms/1000ft (4.6 ohms/km)
- Outer Conductor: 1.65 ohms/1000ft (5.4 ohms/km)
- Voltage Withstand: 2500 Volts DC
- Jacket Spark: 8000 Volts RMS
- Peak Power: 16 kW
- Weight: 1.21 lb / 550 g
Note Currently out of stock
Available Quantity 0
UPC 710931502947
SKU mingleTEW-L406
Item TRENDnet TEW-L412 12 meters LMR400 N-Type Male to N-Type Female Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $77.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TEW-L412
- Features:
- Extend your wireless antenna upto 12 meters (39.3 ft.)
- Wi-Fi Compliant with 2.4GHz 802.11 b/g & 5GHz 802.11a Devices for extending wireless networks
- N-Type Male to N-Type Female Connector
- Optimal placement of your existing Wi-Fi Device permits you to maximize its wireless performance
- Flexible outer conductor allows the tightest bend radius available for any cable of similar size and performance
- Provides flexible Low-loss communication for wireless antenna
- 50dB RF Shielding is 10 dB greater than typical single shielded coax (40 dB)
- Multi-ply bonded outer foil conductor is rated conservatively at > 90 dB
- Weatherproof cable design for outdoors exposure with best materials for UV resistance
- Polyethylene jacketed cable designed for outdoor use
- Easy and quick deployment into a WLAN environment
- Construction:
- Inner Conductor (Solid BC): 0.108 inch / 2.74 mm
- Dielectric (Foam PE): 0.285 inch / 7.24 mm
- Outer Conductor (Aluminum Tape): 0.291 inch / 7.39 mm
- Over Braid (Tinned Copper): 0.320 inch / 8.13 mm
- Jacket (PE): 0.405 inch / 10.29 mm
- Mechanical:
- Bend Radius: Installation: 1.0 inch / 25.4 mm
- Bend Radius: Repeated: 4.0 inch / 101.6 mm
- Bending Moment: 0.5 ft-lb / 0.68 N-m
- Weight: 0.068 lb/ft / 0.10 kg/m
- Tensile Strength: 160 lbs / 72.6 kg
- Flat Plate Crush: 40 lb/inch / 0.71 kg/mm
- Electrical:
- Cut-off Frequency: 16.2 GHz
- Velocity of Propagation: 85%
- Dielectric Constant: 1.38
- Time Delay: 1.20 nS/ft / 3.92 nS/m
- Impedance: 50 ohms
- Capacitance: 23.9 pF/ft / 78.4 pF/m
- Inductance: 0.060uH/ft / 0.20 uH/m
- Shielding Effectiveness: > 90 dB
- DC Resistance: 1.39ohms/1000ft / 4.6 ohms/km
- Inner Conductor Outer Conductor: 1.65 ohms/1000ft / 5.4 ohms/km
- Voltage Withstand: 2500 Volts DC
- Jacket Spark: 8000 Volts RMS
- Peak Power: 16 kW
Note Currently out of stock
Available Quantity 0
UPC 710931502954
SKU mingleTEW-L412
Item TRENDnet TPE-TG80G 8-Port Gigabit GREENnet PoE+ Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $125.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TPE-TG80G
- Features:
- IEEE 802.3at and IEEE 802.3af Gigabit and 802.3af PoE compliant
- Supports PoE Class 2 (7 watts) , 3 (15.4 watts), and 4 (30 watts)
- Provides up to 30 watts for PoE+
- Provides up to 15.4 watts for PoE
- Up to 75% GREENnet power savings
- Automatically detects the PoE class level of a Powered Device
- Full wire-speed non-blocking reception and transmission
- Store-and-forward switching method
- Back pressure Flow Control for Half-Duplex mode
- IEEE 802.3x Flow Control for Full-Duplex mode
- Power saving technology powers down unused ports and when a connected device is in standby mode
- Jumbo Frame support up to 9K
- Plug and Play
- Sturdy metal case
- Standard:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3at Power over Ethernet (PoE+)
- IEEE 802.3af Power over Ethernet (PoE)
- IEEE 802.3X Flow Control
- IEEE 802.3az Energy Efficient Ethernet
- Ports: 8x Gigabit Auto-MDIX PoE / PoE+ ports
- Data Transfer Rate:
- Ethernet: 10/20 Mbps (Half / Full Duplex)
- Fast Ethernet: 100/200 Mbps (Half / Full Duplex)
- Gigabit: 2000 Mbps (Full Duplex)
- Forwarding Rate:
- 1000 Mbps: 1,488,000 pps
- 100 Mbps: 148,800 pps
- 10 Mbps: 14,880 pps
- Data RAM Buffer: 96 Kbytes
- Address Table: 1K MAC entries
- Switch Fabric: 16 Gbps
- Diagnostic LEDs: Power, PoE, 1000 Mbps, Link/Activity
- Power:
- Input: 100-240V 50/60 Hz, 2.1A
- Output: 52VDC, 2.31A External Power Adapter
- Power Consumption:
- Min: 5 watts (standby)
- Max:120 watts
- PoE Max: 105 watts
- 7x 15 watts PoE devices connected or 3 x 30 watts PoE+ devices connected
- Power Over Ethernet:
- Up to 15.4 watts for PoE
- Up to 30 watts for PoE+
- PoE - pin 3, 6 for power+ and pin 1, 2 for power- (mode A)
- Certifications: CE, FCC
- Dimensions: 5.6 x 3.7 x 1.2 inch / 142.0 x 95.0 x 30.0 mm
- Weight: 14.0 oz. / 400.0 g
Note Currently out of stock
Available Quantity 0
UPC 710931505191
SKU mingleTPE-TG80G
Item TRENDnet TPE-TG82G 8-Port Gigabit PoE+ Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $98.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TPE-TG82G
- Features:
- Supplies up to 30W of PoE+ power per port with a total power budget of 61W. Supports both PoE (802.3af) and PoE+ (802.3at) devices
- Eight gigabit PoE+ ports
- 16Gbps switching capacity
- Sends larger packets, or Jumbo Frames (up to 9KB) for increased performance
- Embedded GREENnet technology reduces power consumption
- Sturdy metal housing
- LED indicators convey port status
- Standards:
- IEEE 802.3/3u/3x/3ab/3af/3at/3az
- IEEE 802.1p
- Device Interface: 8x Gigabit PoE/PoE+ Ports, LED indicators
- Data Transfer Rate:
- Ethernet: 10/20 Mbps (Half / Full Duplex)
- Fast Ethernet: 100/200 Mbps (Half / Full Duplex)
- Gigabit: 2000 Mbps (Full Duplex)
- Performance:
- Data RAM Buffer: 128KB
- Switch Fabric: 16Gbps
- MAC Address Table: 8K entries
- Forwarding rate: 11.9Mpps (64-byte packet size)
- Jumbo Frame: 9K
- PoE:
- PoE budget: 61W
- Pin 3,6 for power+ and pin 1,2 for power- (mode B)
- Power:
- Input: 100-240V 50/60 Hz, 1.2A
- Output: 54VDC, 1.67A
- Consumption: 36 Watts (Max)
- Certifications: CE, FCC
- Dimensions: 5.9 x 3.7 x 1.2 inch / 150.0 x 95.0 x 30.0 mm
- Weight: 14.0 oz / 400.0 g
Note Currently out of stock
Available Quantity 0
UPC 710931161083
SKU mingleTPE-TG82G
Item TRENDnet TI-G102 10-Port Hardened Industrial Gigabit DIN-Rail Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $304.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TI-G102
- Features:
- 8 Gigabit ports plus 2 Gigabit RJ-45 / SFP shared ports
- IP30 rated metal enclosure with included DIN-rail and wall mount hardware
- 20 Gbps switching capacity
- Dual redundant power inputs with overload current protection (power supply sold separately, models: TI-M6024 / 48VDC3000)
- Alarm relay triggered by power failure of primary and / or redundant power
- Sends larger packets, or Jumbo Frames (up to 10 KB), for increased performance
- Industrial switch is rated for an operating temperature range of -40 - 75 C (-40 - 167 F)
- Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)
- Grounding point protects equipment from external electrical surges
- Standards: IEEE 802.3/ 3u/ 3ab/ 3z/ 3x
- Interface:
- Ports: 8x Gigabit Ports, 2x Gigabit Ethernet Ports, 2x Shared SFP Slots
- Others: 6-pin removable terminal block, LED indicators, DIN-Rail mount, Wall mount, Grounding point
- Data Transfer Rate:
- Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
- Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
- Gigabit: 2000 Mbps (full duplex)
- Performance:
- Data RAM Buffer: 2048 KB
- Switching Fabric: 20 Gbps
- MAC Address Table: 16 K entries
- Forwarding Rate: 14.8 Mpps (64-byte packet size)
- Special Features:
- Hardened components rated for extreme temperatures
- Dual redundant power inputs
- Auto-Negotiation
- Auto store and forward architecture
- Automatic address learning and address aging
- ESD 6KV protection
- Power:
- Input: 12 - 56 V DC
- Compatible Power Supply: TI-M6024 (sold separately)
- Consumption: 5.76 W max.
- Terminal Block:
- Redundant power inputs, alarm relay contact, 6 pin
- Wire range: 0.34 mm^2 to 2.5 mm^2
- Solid wire (AWG): 12-24 / 14-22
- Stranded wire (AWG): 12-24 / 14-22
- Torque: 5 lb. - In / 0.5 Nm / 0.56 Nm
- Wire strip length: 7-8 mm
- Alarm Relay Contact:
- Relay outputs with current carrying capacity of 1 A, 24 V DC
- Open circuit mode when two power sources are connected
- Short circuit mode when only one power source is connected
- MTBF: 510,400 hours
- Housing:
- IP30 metal case
- DIN-rail mount
- Wall mount
- Grounding point
- ESD 6 KV protection
- Certifications:
- CE
- FCC
- Shock (EN 60068-2-27)
- Freefall (EN 60068-2-32)
- Vibration (EN 60068-2-6)
- Dimensions: 6.1 x 4.7 x 1.9 inch / 155.0 x 120.0 x 48.0 mm
- Weight: 1.1 lbs / 415.0 g
- Package Contents:
- TI-G102
- Quick Installation Guide
- Removable terminal block
- DIN-rail and wall mount kit
Note Currently out of stock
Available Quantity 0
UPC 710931160925
SKU mingleTI-G102
Item TRENDnet TI-MGBS10 1000Base-LX Industrial SFP Single-Mode LC Module (10km)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $45.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TI-MGBS10
- Features:
- Compliant with IEEE 802.3z Gigabit Ethernet
- ANSI Fiber Channel compliant
- Small Form-Factor Pluggable (SFP) and Multi-Source Agreement (MSA) compliant
- Wide operating temperature range of -40 - 85 C (-40 - 185 F)
- Supports data rates of up to 1.25Gbps
- Transmission distance of up to 10km (6.2 miles)
- Low Electromagnectic Interference (EMI) design
- Supports 1310nm single-mode network transmissions
- Duplex LC optical interface
- Low power consumption
- Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z
- Device Interface:
- SFP MSA Compliant
- LC duplex connector
- Data Transfer Rate: 1.25Gbps
- Wavelength: 1310 nm
- Optical Output Power: -3 ~ -3 dBm
- Distance: 10km (6.2 miles)
- Special Features: Hot pluggable; Metal enclosure
- Sensitivity: -23 dBm
- Power Consumption: 1W
- Certifications: CE, FCC
- Dimensions: 2.2 x 0.5 x 0.3 inch / 57.0 x 13.0 x 8.5 mm
- Weight: 0.67 oz / 19.0 g
Note Currently out of stock
Available Quantity 0
UPC 710931161052
SKU mingleTI-MGBS10
Item TRENDnet TI-MGBSX 1000Base-SX Industrial SFP Multi-Mode LC Module (550 m)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $41.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TI-MGBSX
- Features:
- Compliant with IEEE 802.3z Gigabit Ethernet
- ANSI Fiber Channel compliant
- Small Form-Factor Pluggable (SFP) and Multi-Source Agreement (MSA) compliant
- Wide operating temperature range of -40 - 85 C (-40 - 185 F)
- Supports data rates of up to 1.25 Gbps
- Transmission distance of up to 550 m (1804 ft.)
- Low Electromagnetic Interference (EMI) design
- Supports 850 nm multi-mode network transmissions
- Duplex LC optical interface
- Low power consumption
- Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z
- Device Interface:
- SFP MSA Compliant
- LC duplex connector
- Data Transfer Rate: 1.25Gbps
- Wavelength: 850 nm
- Optical Output Power: -9 ~ -3 dBm
- Distance: 550 m (1804 ft.)
- Special Features: Hot pluggable; Metal enclosure
- Sensitivity: -20 dBm
- Power Consumption: 1W
- Certifications: CE, FCC
- Dimensions: 2.2 x 0.5 x 0.3 inch / 57.0 x 13.0 x 8.5 mm
- Weight: 0.6 oz / 17.0 g
Note Currently out of stock
Available Quantity 0
UPC 710931161045
SKU mingleTI-MGBSX
Item TRENDnet TI-PG62 6-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $218.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Note Currently out of stock
Available Quantity 0
UPC 710931160604
SKU mingleTI-PG62
Item TREDnet TK-1603R 16-Port Rack Mount USB KVM Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $235.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TK-1603R
- Features:
16-Port USB KVM Switch
Supports both USB and PS/2 Interface for console port
Supports Microsoft IntelliMouse, IntelliMouse Explorer, Logitech NetMouse, Optical Mouse
Supports Windows 98SE/ME/2000/XP/2003 Server, Linux, Mac OS and more
High video quality- up to 2048 x 1536 VGA resolution
Firmware upgradeable via PC port
Auto-Scan for monitored PCs with adjustable scan interval from 10-99 seconds
Keyboard status restored when switching between PCs
LEDs display for easy status monitoring
Beeping sound for port switching confirmation (enable/disable)
Hot-Key or push button switching
Plug & Play and Hot-Pluggable
Standard 19 inch (1U) rack mount design
Management: 16 Computers
Standard: USB 1.1 Compliant
PC Port: 16x VGA HDB 15-pin (female)
Console Port:
- 1x USB (Type A) / PS/2 (6-pin Mini Din) Mouse
- 1x USB (Type A) / PS/2 (6-pin Mini Din) Keyboard
- 1x VGA HDB 15-pin (female)
Supported OS: Windows 98(SE)/ME/ 2000/XP/2003 Server, Linux, Mac and more
PC Selection: Hot-Key or Push Buttons
Auto-Scan Interval: 10-100 seconds (Programmable through Hot-Key)
LEDs: On-line (Red), Select (Green)
Keyboard Status: Saved & Restored
Power Adapter: 9V DC 1A External Power Adapter
Certification: CE, FCC
Dimensions: 407 x 165 x 45mm / 16.0 x 6.5 x 1.8in.
Weight: 2.04kg / 4.5lb
Note Currently out of stock
Available Quantity 0
UPC 710931304329
SKU mingleTK-1603R
Item TRENDnet TK-204UK 2-Port DVI/USB KVM Switch w/ Audio Kit
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $103.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TK-204UK
- Features:
- 2-port compact desktop DVI USB KVM switch with audio and mic
- USB console support for USB keyboard, mouse and high-speed USB devices
- Audio and microphone switching for uninterrupted multimedia experience across multi-platforms
- USB 2.0/1.1 specification compliant USB interface power
- Independent simultaneous switching of both PC and audio and mic channel
- Multi-platform support for PCs and Macintosh G3/G4, iMAC
- Hot-plugging PCs for maintenance without powering down the KVM switch or PCs
- Switching software client for easy software switching on Windows and Mac platform
- User definable hotkeys additional universal port switching hotkey - ScrollLock + ScrollLock - for non-Windows OS on PC platform
- Channel selection by push button, keyboard hotkeys and switching software client (for Windows/Mac)
- USB interface power LED indicators for easy status monitoring
- Digital video resolution 1920 x 1200
- Interface: DVI-I & DVI-D Compliant
- PC Port connection:
- 2x USB type B
- 2x DVI-I (integrated with audio&mic)
- Console Port Connector:
- 2x USB Type A (keyboard & mouse & USB 2.0/1.1 Devices)
- 1x DVI 15-pin female
- 1x 3.5mm audio jack
- 1x 3.5mm mic jack
- Cable: 2x detachable DVI/audio and mic combo cable; 2x USB cable
- PC Selection: Push button, hotkeys, switching software (for Windows/Mac)
- Keyboard/Mouse Emulation: PS/2
- LED: 2x (green - PC1 / blue - PC2)
- VGA Resolution: 1920 x 1200 (digital)
- Power: 5V DC 2A external power adapter
- Certification: CE, FCC
- Dimensions (WxLxH): 65.5 x 154.0 x 27.0 mm
- Weight: 18.4 oz / 520.0 g
Note Currently out of stock
Available Quantity 0
UPC 710931304411
SKU mingleTK-204UK
Item TRENDnet TK-215I 2-Port HDMI KVM Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $90.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TK-215I
- Features:
- Control two computers with one set of console controls
- Works with displays with an HDMI port
- Full HD 1080p resolution
- HDMI and 3.5 mm analog audio
- Fully integrated cabling
- Ergonomic computer toggle switch
- No CD installation
- USB Powered - No external power adapter
- Console Port on KVM:
- Keyboard: USB
- Mouse: USB
- Monitor: HDMI 1.3 (19-pin)
- Speaker Jack: 3.5 mm
- Microphone Jack: 3.5 mm
- Computer Connections (up to 2):
- Keyboard / Mouse: USB 2.0 type A
- Monitor: HDMI 1.3 (19-pin)
- Speaker Jack: 3.5 mm
- Microphone Jack: 3.5 mm
- Monitor Resolution: 1920 x 1080 @ 60 Hz
- Audio Support:
- 5.1 Audio support over HDMI cables
- Analog audio over speaker and microphone jacks
- LED: Computer 1 and Computer 2
- Switching Control:
- One touch toggle switch
- Keyboard hot key commands
- KVM Switch Software
- Supported OS: Windows and Mac
- Certifications: CE, FCC
- Dimensions:
- Unit: 3.3 x 2.3 x 1.1 inch / 85.0 x 58.0 x 28.0 mm
- Integrated Cable: 3 ft / 85.0 cm
- Toggle Switch: 5 ft. / 150.0 cm
- Weight: 12.3 oz. / 350.0 g
- Package Contents:
- TK-215i
- Quick Installation Guide
- CD-ROM (Utility & User's Guide)
Note Currently out of stock
Available Quantity 0
UPC 710931170108
SKU mingleTK-215I
Item TRENDnet TK-408K PS2 4-Port Audio KVM Switch w/ Cables
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $60.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TK-408K
- Features:
- Use one keyboard, monitor, and mouse to control four computer
- 4 sets of PS/2, VGA and audio & microphone cables
- Support Microsoft IntelliMouse, Optical Mouse, Logitech NetMouse and more
- Superior video quality Upto 2048 x 1536 resolution
- Support Windows 98(SE)/ME/2000/XP/2003 server and Linux
- Hot-Plug feature, add PC or remove the connected PC for maintenance without powering down the KVM Switch or other PC's
- No software required, easy PC selection via push button or hot-key commands
- Auto-scan mode for monitoring PC's
- LED display for easy status monitoring
- PS/2 Interface Power method
- Number of PC Supported: 4
- Cable: 4 sets of 1.8M (6ft.) KVM & Audio Cables
- Cable Interface (all male):
- KVM cable: To KVM- 1x VGA/SVGA HDB 15-pin; To PC- 1x PS/2 Keyboard 6-pin Mini Din, 1x PS/2 Mouse 6-pin Mini Din, 1x VGA/SVGA HDB 15-pin
- Audio cable: To KVM- 1x 3.5mm audio in/out jack, 1x 3.5mm microphone in/out jack; To PC- 1x 3.5mm audio in/out jack, 1x 3.5mm microphone in/out jack
- Console Connectors (all female):
- 1x PS/2 Keyboard 6-pin Mini Din
- 1x PS/2 mouse 6-pin Mini Din
- 1x VGA/SVGA HDB 15-pin
- 1x 3.5mm audio in/out jack
- 1x 3.5mm microphone in/out jac
- Port Selection: Push Buttons or Hot-Key Commands
- Auto-Scan Interval: 5 seconds
- Keyboard State: Saved and Restored
- Power Type: PS/2 Interface Power
- Certifications: CE, FCC
- Dimensions: 6.6 x 3.2 x 1.1 inch / 167 x 80 x 28 mm
- Weight: 6.3 oz / 178 g
Note Currently out of stock
Available Quantity 0
UPC 710931304275
SKU mingleTK-408K
Item TRENDnet TK-423K 4-Port USB&PS/2 KVM Switch Kit, w/ Audio
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $135.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TK-423K
- Features:
- Manage upto 4x computers/servers with one set of console devices
- All required cabling included
- Cables from the KVM switch to the computers/servers feature VGA and PS/2 connectors
- Supported console connections are as follows: PS/2 or USB keyboard and mouse ports, VGA monitor port and speaker/mic port
- Audio and microphone support
- Audio/mic port selection may be independent of keyboard, video and mouse port selection
- Control computer/server selection with front push buttons and keyboard hotkeys
- Supports Universal Host and Open Host Controller Interface (UHCI/OHCI)
- Multiple platforms supported: Windows 98, XP, Vista, Mac, Linux and more
- Port switching confirmed by LED status indicators and audio tone
- High quality VGA resolution upto 2048 x 1536
- Management: 4x Computers
- PC Port Connection:
- 4x USB type B
- 4x VGA HDB 15pin female
- 4x 3.5mm audio in/out jack
- 4x 3.5mm microphone in/out jack
- Console Port Connectors:
- 2x USB 1.1 type A for keyboard/ mouse
- 1x PS/2 keyboard 6-pin mini DIN female
- 1x PS/2 mouse 6 pin mini DIN female
- 1x VGA HDB 15 pin female
- 1x 3.5mm audio in/out jack
- 1x 3.5mm microphone in/out jack
- KVM Cables:
- 4x KVM Multiple Connection Cable
- 4x KVM Audio/Microphone Cable
- Cable Interface:
- 1x VGA 15pin male to male connector
- 1x USB type A connector
- 1x PS/2 Connector (Keyboard connector)
- 1x USB to PS/2 Gender Connector (Support for PS/2 Mouse)
- PC Selection: Hotkey / Push button
- LED: 2x LED
- Auto Scan Interval: Programmable 5~99 seconds
- VGA Resolution: 2048 x 1536
- Power Adapter: 5V DC 2A external power adapter
- Certification: CE, FCC
- Dimensions (WxLxH): 117.5 x 255 x 45 mm
- Weight: 35.2 oz / 1000 g
Note Currently out of stock
Available Quantity 0
UPC 710931304404
SKU mingleTK-423K
Item TRENDnet TK-803R 8-Port Rack Mount USB PS2 KVM Switch w/o Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $145.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TK-803R
- Features:
- Controls up to 8 computers or servers.
- Supports both USB and PS/2 Interface for console port
- Supports Windows, Linux, Mac OS and more
- High video quality, up to 2048 x 1536 VGA resolution
- Firmware upgradeable via PC port
- Auto-scan for monitored PCs with adjustable scan interval from 10-99 seconds
- Keyboard status restored when switching between computers
- LEDs display for easy status monitoring
- Beeping sound for port switching confirmation (enable/disable)
- Keyboard hot key command or push button switching
- Plug & Play and Hot-Pluggable
- Standard 19" (1U) rack mount design
- Connections: 8 computers/servers
- Standard: USB 1.1 Compliant
- PC Ports: 8x VGA HDB 15-pin (female)
- Console Port:
- 1x USB (Type A)/PS/2 (6-pin mini-DIN) mouse
- 1x USB (Type A)/PS/2 (6-pin mini-DIN) keyboard
- 1x VGA HDB 15-pin (female)
- Cable Interface (Sold Separately):
- To KVM: 1x VGA HDB 15-pin (male)
- To Computer: 1x VGA HDB 15-pin (male), 1x USB (Type A)
- Supported OS: Windows, Linux, Mac and more
- PC Selection: Keyboard hot key command or push button
- Auto-Scan Interval: 10-99 seconds (Programmable through hot key)
- LEDs: On-line (Red), Select (Green)
- Keyboard Status: Saved & restored
- Power Adapter:
- Input: 100 ~ 240 V AC 50~60 Hz
- Output: 9 V DC 1 A external power adapter
- Certification: CE, FCC
- Dimensions: 16.0 x 6.5 x 1.8 inch / 407.0 x 165.0 x 45.0 mm
- Weight: 4.0 lbs / 1.83 kg
- Package Contents:
- TK-803R
- Quick Installation Guide
- Power Adapter (9 V DC, 1 A)
- Rack mount kit
Note Currently out of stock
Available Quantity 0
UPC 710931304305
SKU mingleTK-803R
Item TRENDnet TK-C10 PS/2 KVM Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TK-C10
- High-grade KVM cable
- Monitor: 15-pin HDDB type
- Keyboard & Mouse: PS/2 type 6-pin mini Din
- Length: 10 feet / 3.1 meters
Note Currently out of stock
Available Quantity 0
UPC 710931304053
SKU mingleTK-C10
Item TREDnet TK-EX3(Version v1.0R) KVM Extension Kit
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $155.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: TK-EX3
- Features:
- Extends keyboard, mouse, and monitor distances up to: 150m (490ft.) at 1280 x 1024 resolution and 100m (328ft.) at 1600 x 1200 resolution
- Controls multiple servers remotely when used with a KVM switch
- Displays high quality resolution up to 1600 x 1200 pixels
- Provides local and remote console ports to access one computer
- Connect the local console (transmitter) to the remote console (receiver) with an Ethernet cable
- Cat. 5, Cat. 5E or Cat. 6 Ethernet cable compliant
- Fine-tune resolution on the remote consoles viewing monitor, with Gain (resolution adjustment) and Equalization (contrast correction)
- PS/2 and USB interface support for loca console (transmitter)
- PS/2 interface support for remote console (receiver)
- Data and power LED indicators
- Supports Windows, Mac, and Linux operating systems
- No driver or software installation required
- Connections: Connect to a computer or KVM switch
- Connectors:
- Transmitter: HDB 15-pin VGA; USB type B; RJ-45 Port
- Receiver: HDB 15-pin VGA; PS/2 keyboard & mouse; RJ-45 port; Power connector
- Resolution
- Upto 100m (328ft.) with 1600 x 1200 resolution
- Upto 150m (490ft.) with 1280 x 1024 resolution
- Cables (included): 1x VGA cable (VGA to VGA and PS/2), 1.2m/ 4ft; 1x USB cable (type A to type B), 1.2m/ 4ft
- LEDs: Power, Link
- Power: 9V DC, 1A
- Supported OS: Windows 7 (32/-64bit)/ Vista (32/64-bit)/ XP (32/64-bit)/ 2000 Linux
- Dimensions(WxLxH)): 65 x 130 x 25mm / 2.6 x 5 x 1 inch
- Weight:
- Transmitter: 275g / 9.7oz
- Receiver: 290g / 10oz
Note Currently out of stock
Available Quantity 0
UPC 710931304459
SKU mingleTK-EX3
|
