Product Description

Specifications

• Mfr Part Number: B550M-HDV
• Unique Feature:
  • ASRock Super Alloy
    - Premium 50A Power Choke
    - Sapphire Black PCB
    - High Density Glass Fabric PCB
  • ASRock Hyper M.2 (PCIe Gen4x4)
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU:
  • Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors
  • 6 Power Phase design
• Chipset: AMD B550
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 2 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
  • AMD Ryzen series APUs support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
  • Max. capacity of system memory: 64GB
  • Supports Extreme Memory Profile (XMP) memory modules
  • 15 Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VDDP Voltage Multi-adjustment
• Graphics:
  • Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB.
  • Three graphics output options: D-Sub, DVI-D and HDMI
  • Supports Triple Monitor
  • Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
  • Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required)
  • Supports HDR (High Dynamic Range) with HDMI 2.1
  • Supports HDCP 2.3 with DVI-D and HDMI 2.1 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port
  • Supports Microsoft PlayReady
• Audio:
  • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)
  • Supports Surge Protection
• LAN:
  • PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  • Realtek RTL8111H
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE
• Slots:
  • AMD Ryzen series CPUs (Matisse)
    - 1 x PCI Express 4.0 x16 Slot (PCIE1: x16 mode)
  • AMD Ryzen series APUs (Renoir)
    - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
    - 1 x PCI Express 3.0 x1 Slot
• Storage:
  • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Renoir)
• Connector:
  • 1 x SPI TPM Header
  • 1 x COM Port Header
  • 1 x Chassis Intrusion and Speaker Header
  • 1 x CPU Fan Connector (4-pin)
  • 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
  • 1 x 24 pin ATX Power Connector
  • 1 x 4 pin 12V Power Connector
  • 1 x Front Panel Audio Connector
  • 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
  • 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O:
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x D-Sub Port
  • 1 x DVI-D Port
  • 1 x HDMI Port
  • 2 x USB 2.0 Ports (Supports ESD Protection)
  • 4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI:
  • Software
    - ASRock Motherboard Utility (A-Tuning)
    - ASRock XFast LAN
  • UEFI
    - ASRock Full HD UEFI
    - ASRock Instant Flash
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD, I/O Shield
  • 2 x SATA Data Cables
  • 1 x Screw for M.2 Socket
• Hardware Monitor:
  • Temperature Sensing: CPU, Chassis Fans
  • Fan Tachometer: CPU, Chassis Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis Fans
  • Fan Multi-Speed Control: CPU, Chassis Fans
  • CASE OPEN detection
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor:
  • Micro ATX Form Factor: 9.0-in x 7.9-in, 23.0 cm x 20.1 cm
  • Solid Capacitor design
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)

Available Quantity

5

UPC

Does not apply

SKU

mingleB550M-HDV

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Available Quantity

5

UPC

889349813638

SKU

mingleWS X299 PRO/SE

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Available Quantity

5

UPC

889523013755

SKU

mingleH310M S2H GSM

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

1. Single socket H4 (LGA 1151) supports
Intel Xeon processor E3-1200 v5,
Intel 6th Gen. Core i3 series,
Intel Celeron and Intel Pentium

2. Intel C236 chipset

3. Up to 64GB Unbuffered ECC UDIMM DDR4 2133MHz; 4x DIMM slots

4. Expansion slots:
1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x4 (in x8)

5. Quad GbE LAN with Intel i210-AT

6. 8x SATA3 (6Gbps) via C236,RAID 0, 1, 5, 10

7. I/O: 1x VGA, 2x COM, TPM 1.2 header

8. 2x SuperDOM with built-in power

9. 5x USB 3.0 (2 rear + 2 via header +1 Type A), 6x USB 2.0 (2 rear + 4 via headers)

10. M.2 NGFF connector

11. Support Intel VHD with selected CPU

Form Factor
microATX
CPU
Single Socket H4 (LGA 1151) supports:
Intel Xeon processor E3-1200 v5,
Intel 6th Gen Core^TM i3,
Intel Pentium,
Intel Celeron processors
CPU TDP up to 80W
Memory Capacity
4x 288-pin DDR4 DIMM slots
Up to 64GB DDR4 ECC UDIMM
Memory Type
2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (UDIMM) gold-plated DIMMs
DIMM Sizes
16GB, 8GB, 4GB
Memory Voltage
1.2 V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
Chipset
Intel C236 chipset
SATA
SATA3 (6Gbps) via C236 controller
RAID 0, 1, 5, 10 support
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
ASPEED AST2400 BMC
Network Controllers
Quad Intel I210-AT Gigabit Ethernet LAN ports
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Graphics
ASPEED AST2400 BMC
Input / Output
SATA : 8x SATA3 (6Gbps) ports ,
LAN : 4x RJ45 Gigabit Ethernet LAN ports , 1x RJ45 Dedicated IPMI LAN port
USB : 5x USB 3.0 ports (2 rear + 2 via header + 1 Type A) , 6x USB 2.0 ports (2 rear + 4 via header)
Video : 1x VGA port
Serial Port / Header : 2x COM ports (1 rear, 1 header)
SuperDOM : 2x SuperDOM (Disk on Module) ports with built-in power
TPM : 1x TPM 1.2 20-pin Header
Expansion Slots
1x PCI-E 3.0 x8 (in x16) slot
1x PCI-E 3.0 x8 slot
1x PCI-E 3.0 x4 (in x8) slot
M.2
Interface : PCI-E 3.0 x2
Form Factor : 2280
BIOS Features

Plug and Play (PnP)
APM 1.2
DMI 2.3
PCI 2.3
ACPI 1.0 / 2.0 / 3.0 / 4.0
USB Keyboard support
Hardware BIOS Virus protection
SMBIOS 2.7.1
UEFI 2.3.1
RTC (Real Time Clock) Wakeup
Software
Intel Node Manager
IPMI 2.0 with KVM support
NMI
Watch Dog
SuperDoctor 5
Power Configurations
ACPI Power Management
Keyboard Wakeup from Soft-Off
CPU Fan auto-off in sleep mode
Power-on mode for AC power recovery
Voltage
Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages.
FAN
Total of 5 fan headers supporting up to 5 fans
5 fans with tachometer status monitoring
Status monitor for speed control
Status monitor for on/off control
Low noise fan speed control
Pulse Width Modulated (PWM) fan connectors

Available Quantity

5

UPC

672042205929

SKU

mingleMBD-X11SSH-LN4F-B

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: B550 TAICHI
• Unique Feature:
  • ASRock USB 3.2 Gen2
  • ASRock Super Alloy
  • Intel 2.5G LAN
  • Intel 802.11ax WiFi
  • ASRock Steel Slot Gen4
  • ASRock Full Coverage M.2 Heatsink
  • ASRock Hyper M.2 (PCIe Gen4x4)
  • ASRock Ultra USB Power
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU:
  • Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors
  • Digi Power design
  • 16 Power Phase design
• Chipset: AMD B550
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 4 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 5000+(OC) / 4933(OC) / 4866(OC) / 4800(OC) / 4733(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
  • AMD Next Generation Ryzen series APUs support DDR4 5200+(OC) / 5100(OC) / 5000(OC) / 4933(OC) / 4866(OC) / 4800(OC) / 4733(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
  • Max. capacity of system memory: 128GB
  • Supports Extreme Memory Profile (XMP) memory modules
  • 15 Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VPPM, VTT_DDR Offset, CPU VDD 1.8 Voltage Multi-adjustment
• Graphics:
  • Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB.
  • Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers
  • Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports DisplayPort 1.4 Input with max. resolution up to 5K (5120x2880)@120Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required)
  • Supports HDR (High Dynamic Range) with HDMI 2.1
  • Supports HDCP 2.3 with HDMI 2.1 and DisplayPort 1.4 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 2.1 and DisplayPort 1.4 Ports
  • Supports Microsoft PlayReady
• Audio:
  • 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
  • Premium Blu-ray Audio support
  • Supports Surge Protection
  • 120dB SNR DAC with Differential Amplifier
  • NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets)
  • Pure Power-In
  • Direct Drive Technology
  • PCB Isolate Shielding
  • Impedance Sensing on Rear Out port
  • Individual PCB Layers for R/L Audio Channel
  • Gold Audio Jacks
  • 15 Gold Audio Connector
  • Nahimic Audio
• LAN:
  • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
  • GigaLAN Intel I225V
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE
• Wireless LAN:
  • Intel 802.11ax WiFi Module
  • Supports IEEE 802.11a/b/g/n/ax
  • Supports Dual-Band (2.4/5 GHz)
  • Supports WiFi6 802.11ax (2.4Gbps)
  • 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  • Supports Bluetooth 5.1 + High speed class II
  • Supports MU-MIMO
• Slots:
  • AMD Ryzen series CPUs (Matisse)
    - 3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE5: single at Gen4x16 (PCIE1); dual at Gen4x8 (PCIE1) / Gen4x8 (PCIE3); triple at Gen4x8 (PCIE1) / Gen4x8 (PCIE3) / Gen3x4 (PCIE5))
  • AMD Ryzen series APUs (Renoir)
    - 3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE5: single at Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3); triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen3x4 (PCIE5))
    - 2 x PCI Express 3.0 x1 Slots
    - Supports AMD Quad CrossFireX, 3-Way CrossFireX and CrossFireX
    - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ax module (on the rear I/O)
    - 15 Gold Contact in VGA PCIe Slot (PCIE1)
• Storage:
  • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 4 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Renoir)
  • 1 x Ultra M.2 Socket (M2_2), supports M Key type 2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
• Connector:
  • 1 x Power LED and Speaker Header
  • 2 x RGB LED Headers
  • 2 x Addressable LED Headers
  • 1 x CPU Fan Connector (4-pin)
  • 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
  • 5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
  • 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  • 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
  • 1 x Front Panel Audio Connector (15 Gold Audio Connector)
  • 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
  • 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection)
  • 1 x Front Panel Type C USB 3.2 Gen2 Header (Supports ESD Protection)
  • 1 x Dr. Debug with LED
  • 1 x Power Button with LED
  • 1 x Reset Button with LED
  • 1 x Clear CMOS Button
• Rear Panel I/O:
  • 2 x Antenna Ports
  • 1 x HDMI Port
  • 1 x DisplayPort 1.4
  • 1 x Optical SPDIF Out Port
  • 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection)
  • 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection)
  • 4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
  • 2 x USB 2.0 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • 1 x Clear CMOS Button
  • 1 x BIOS Flashback Button
  • HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)
• Software and UEFI:
  • Software
    - ASRock Motherboard Utility (A-Tuning)
    - ASRock Polychrome SYNC
    - ASRock XFast LAN
  • UEFI
    - ASRock Full HD UEFI
    - ASRock Instant Flash
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD
  • 4 x SATA Data Cables
  • 1 x ASRock WiFi 2.4/5 GHz Antenna
  • 1 x ASRock Screwdriver
  • 2 x Screws for M.2 Sockets
  • 2 x Standoffs for M.2 Sockets
• Hardware Monitor:
  • Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, CPU VDD 1.8V
• Form Factor:
  • ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
  • 2oz Copper PCB
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)

Available Quantity

5

UPC

Does not apply

SKU

mingleB550 TAICHI

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: ROG STRIX B550-I GAMING
• CPU: AMD AM4 Socket 3rd Gen AMD Ryzen Processors
• Chipset: AMD B550
• Memory:
  • 3rd Gen AMD Ryzen Processors
    - 2 x DIMM, Max. 64GB, DDR4
    - 5100(O.C)/5000(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3800(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory
    - Dual Channel Memory Architecture
    - OptiMem II
    - ECC Memory (ECC mode) support varies by CPU.
• Graphic:
  • 1 x HDMI 2.1(4K@60HZ)
  • 1 x DisplayPort 1.4
• Expansion Slots:
  • 3rd Gen AMD Ryzen Processors
    - 1 x PCIe 4.0 x16 (x16 mode)
• Storage:
  • Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
  • 3rd Gen AMD Ryzen Processors:
    - 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
  • AMD B550 Chipset:

    - 1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support

    - 4 x SATA 6Gb/s port(s)

    - Support Raid 0, 1, 10
• LAN:
  • Intel I225-V 2.5Gb Ethernet
  • ASUS LANGuard
• Wireless Data Network:
  • Intel Wi-Fi 6 AX200
  • 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
  • Supports dual band frequency 2.4/5 GHz
  • Supports channel bandwidth: HT20/HT40/HT80/HT160
• Bluetooth: Bluetooth v5.1
• Audio:
  • SupremeFX 7.1 Surround Sound High Definition Audio CODEC S1220A
    - Dual OP Amplifiers
    - Impedance sense for front and rear headphone outputs
    - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
    - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
    - Supports up to 32-Bit/192kHz playback
  • Audio Feature:
    - Rear audio USB Type-C port
    - LED-illuminated design
    - Audio Shielding
    - Premium Japanese audio capacitors
• USB Ports:
  • Rear USB Port ( Total 6 )
    - 4 x USB 3.2 Gen 2 port(s)(1 x USB Type-C +3 x Type-A)
    - 1 x USB 2.0 port(s)
    - 1 x USB 2.0 port(s)(1 x audio USB Type-C )
  • Front USB Port ( Total 5 )
    - 1 x USB 3.2 Gen 2 front panel connector port(s)(1 x USB Type-C)
    - 2 x USB 3.2 Gen 1 port(s)
    - 2 x USB 2.0 port(s)
• Software Features:
  • ROG Exclusive Software
    - RAMCache III
    - ROG CPU-Z
    - GameFirst VI
    - Sonic Studio III + Sonic Studio Virtual Mixer
    - Sonic Radar III
    - DTS Sound Unbound
    - Overwolf
    - Anti-virus software
  • ASUS Exclusive Software Features
  • Armoury Crate
    - Aura Creator
    - Aura Sync
    - AI Noise Cancelling Microphone
  • AI Suite 3:
    - 5-way Optimization
  • TPU
  • EPU
  • DIGI+ VRM
  • Fan Xpert 4
  • Turbo APP
    - EZ update
  • WinRAR
  • UEFI BIOS
  • ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode
  • FlexKey
• ASUS Special Features:
  • Aura Sync
    - Standard RGB header(s)
    - Addressable Gen 2 RGB header(s)
  • ASUS Q-Design
    - ASUS Q-CODE
    - ASUS Q-DIMM
    - ASUS Q-LED (DRAM [yellow],CPU [red], VGA [white], Boot Device [yellow green)
    - ASUS Q-Slot
  • ASUS Thermal Solution
    - Aluminum M.2 heatsink
  • ASUS EZ DIY
    - BIOS Flashback button
    - BIOS FlashBack LED
    - Clear CMOS header
    - Procool
    - Pre-mounted I/O shield
    - SafeSlot
  • Rear audio USB Type-C connector
• Back I/O Ports:
  • 1 x Intel I225-V 2.5Gb Ethernet
  • 1 x DisplayPort
  • 1 x HDMI
  • 4 x USB 3.2 Gen 2 (1 x USB Type-C+3 x Type-A)
  • 2 x USB 2.0 (one port can be switched to USB BIOS FlashBack 1 for audio USB Type-C)
  • 1 x BIOS FlashBack Button(s)
  • 1 x ASUS Wi-Fi Module
  • 3 x LED-illuminated audio jacks
• Internal I/O Ports:
  • 1 x CPU Fan connector(s)
  • 1 x Chassis Fan connector(s)
  • 1 x AIO_PUMP connector
  • 1 x Aura RGB Strip Header(s)
  • 1 x Addressable Gen 2 header(s)
  • 1 x USB 3.2 Gen 1 front panel TypeC connector
  • 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
  • 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  • 2 x M.2 Socket 3 with M Key design, type 2242/2260/2280 storage devices support (Supports both SATA & PCIE SSD)
  • 4 x SATA 6Gb/s connector(s)
  • 1 x 24-pin EATX Power connector(s)
  • 1 x 8-pin ATX 12V Power connector(s)
  • 1 x Front panel audio connector(s) (AAFP)
  • 1 x Thermal sensor connector(s)
  • 1 x Clear CMOS jumper(s)
  • 1 x System panel connector
  • 1 x Speaker connector
  • 1 x VRM_HS_FAN Header
• Accessories:
  • User's manual
  • I/O Shield
  • 4 x SATA 6Gb/s cable(s)
  • 2 x M.2 Screw Package
  • 1 x Supporting DVD
  • 1 x ROG Strix stickers
  • 1 x M.2 bracket
  • 1 x Cable ties pack(s)
  • 1 x Wi-Fi Antenna(s)
  • 1 x Extension cable for Addressable LED
  • 1 x Panel cable
  • 1 x ROG Thank you card
  • 1 x ROG audio USB Type-C cable
• BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
• Manageability: WOL by PME, PXE
• Operating System: Windows 10 64-bit
• Form Factor:

  • Mini ITX Form Factor;

  • 6.7 inch x 6.7 inch ( 17 cm x 17 cm )
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.

Available Quantity

5

UPC

192876786383

SKU

mingleROG STRIX B550-I GAMING

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Available Quantity

5

UPC

824142219393

SKU

mingleB550MPVDHWIFI

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: B550M PRO4
• Unique Feature:
  • ASRock USB 3.2 Gen2
    - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)
    - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s)
  • ASRock Super Alloy
    - XXL Aluminum Alloy Heatsink
    - Premium 50A Power Choke
    - Sapphire Black PCB
    - High Density Glass Fabric PCB
    - 2oz Copper PCB
  • ASRock Steel Slot Gen4
  • ASRock Full Coverage M.2 Heatsink
  • ASRock Hyper M.2 (PCIe Gen4x4)
  • ASRock POST Status Checker (PSC)
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU:
  • Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors
  • Digi Power design
  • 8 Power Phase design
• Chipset: AMD B550
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 4 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 4533+(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
  • AMD Ryzen series APUs support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory
  • Max. capacity of system memory: 128GB
  • Supports Extreme Memory Profile (XMP) memory modules
  • 15 Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VPPM, 1.05V_PROM_S5, 2.5V_PROM, +1.8VSB, VDDP Voltage Multi-adjustment
• Graphics:
  • Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB.
  • Three graphics output options: D-Sub, HDMI and DisplayPort 1.4
  • Supports Triple Monitor
  • Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports DisplayPort 1.4 with max. resolution up to 5K (5120x2880)@120Hz
  • Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required)
  • Supports HDR (High Dynamic Range) with HDMI 2.1
  • Supports HDCP 2.3 with HDMI 2.1 and DisplayPort 1.4 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 2.1 and DisplayPort 1.4 Ports
  • Supports Microsoft PlayReady
• Audio:
  • 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec)
  • Premium Blu-ray Audio support
  • Supports Surge Protection
  • PCB Isolate Shielding
  • Individual PCB Layers for R/L Audio Channel
  • Nahimic Audio
• LAN:
  • PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  • Realtek RTL8111H
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE
• Slots:
  • AMD Ryzen series CPUs (Matisse)
    - 2 x PCI Express x16 Slots (PCIE1: Gen4x16 mode; PCIE3: Gen3 x4 mode)
  • AMD Ryzen series APUs (Renoir)
    - 2 x PCI Express x16 Slots (PCIE1: Gen3x16 mode; PCIE3: Gen3 x4 mode)*
    - 1 x PCI Express 3.0 x1 Slot
    - Supports AMD Quad CrossFireX and CrossFireX
    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
• Storage:
  • 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket (M2_1), supports M Key type 2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Renoir)
  • 1 x M.2 Socket (M2_2), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x2 (16 Gb/s)
• Connector:
  • 1 x COM Port Header
  • 1 x SPI TPM Header
  • 1 x Power LED and Speaker Header
  • 2 x RGB LED Headers
  • 2 x Addressable LED Headers
  • 1 x CPU Fan Connector (4-pin)
  • 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
  • 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
  • 1 x 24 pin ATX Power Connector
  • 1 x 8 pin 12V Power Connector
  • 1 x Front Panel Audio Connector
  • 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
  • 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O:
  • Antenna Bracket
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x D-Sub Port
  • 1 x HDMI Port
  • 1 x DisplayPort 1.4
  • 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection)
  • 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection)
  • 4 x USB 3.2 Gen1 Ports (ASMedia ASM1074 hub) (Supports ESD Protection)
  • 2 x USB 2.0 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI:
  • Software
    - ASRock Motherboard Utility (A-Tuning)
    - ASRock XFast LAN
  • UEFI
    - ASRock Full HD UEFI
    - ASRock Instant Flash
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD, I/O Shield
  • 2 x SATA Data Cables
  • 2 x Screws for M.2 Sockets
• Hardware Monitor:
  • Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, VPPM, 1.05V_PROM_S5, +1.8V, VDDP
• Form Factor:
  • Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
  • Solid Capacitor design
  • 2oz Copper PCB
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)

Available Quantity

5

UPC

Does not apply

SKU

mingleB550M PRO4

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Available Quantity

5

UPC

192876715437

SKU

minglePRIME H410M-A/CSM

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: X11SAE-B
• CPU: LGA1151
  • Supports Intel Xeon E3-1200 v5 Processor
  • Supports 6th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
  • Support up to 95W TDP
• Chipset: Intel C236
• Memory: 4x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, ECC, Unbuffered, Max Capacity of 64GB
• Slots: 2x PCI-Express 3.0 x16 Slots (run at 16/NA or 8/8), 3x PCI-Express 3.0 x1 Slots, 2x PCI Slots (5V, 32bit)
• SATA: 8x SATA3 Ports, Support RAID 0, 1, 5, 10
• Audio: Realtek ALC888S High Definition Audio CODEC
• LAN: Intel I210-AT + Intel PHY I219LM Gigabit Ethernet Controllers
• Ports: 2x USB 3.1 Ports, 6x USB 3.0 Ports (2 rear, 4 via headers), 8x USB 2.0 Ports (2 rear, 6 via headers), 1x DisplayPort, 1x DVI-D Port, 1x HDMI Port, 2x RJ45 LAN Ports
• Form Factor: ATX, 12.0 x 9.6 inch / 30.5 x 22.4 cm

Available Quantity

5

UPC

672042204786

SKU

mingleMBD-X11SAE-B

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Available Quantity

5

UPC

Does not apply

SKU

mingleX570M PRO4

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: X570APRO (X570-A PRO)
• CPU: Supports 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Desktop Processors for Socket AM4
• Chipset: AMD X570 Chipset
• Memory:
• 4 DDR4 memory slots, support up to 128GB (depending on the processor)1
  - 3rd Gen AMD Ryzen Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 Mhz by A-XMP OC MODE
  - 2nd Gen AMD Ryzen Processors, 1st and 2nd Gen AMD Ryzen with Radeon Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 Mhz by A-XMP OC MODE
• Dual channel memory architecture
• Supports non-ECC UDIMM memory
• ports ECC UDIMM memory (non-ECC mode)
• Supports un-buffered memory
• Expansion Slots:
• 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
  - 3rd Gen AMD Ryzen support PCIe 4.0 x16 mode
  - 2nd Gen AMD Ryzen support PCIe 3.0 x16 mode
  - Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics support PCIe 3.0 x8 mode
• 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E3, supports x4 mode)
• 3 x PCIe 3.0 x1 slots1
  * PCI_E2 will be unavailable when installing the PCIe card in PCI_E4 slot. The speeds may vary for different devices
• Onboard Graphics:
  • 1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @24Hz
  • Only support when using Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Processors
  • Maximum shared memory of 2048 MB
• Multi-Graphics:
• Supports 2-Way AMD CrossFire Technology
• Storage:
  • 6 x SATA 6Gb/s ports
  • 2 x M.2 slot (Key M)
    - M2_1 slot (from AMD Processor)
      *Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen)
      *Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics)
      *Supports 2242/ 2260/ 2280/ 22110 storage devices
    - M2_2 slot (from AMD X570 Chipset)
      *Supports PCIe 3.0 x4 and SATA 6Gb/s
      *Supports 2242/ 2260/ 2280 storage devices
• RAID: AMD X570 Chipset Supports RAID 0, RAID 1 and RAID 10
• USB:
• AMD X570 Chipset
  - 6 x USB 3.2 Gen 1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.2 Gen 1 connectors)
  - 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
• AMD Processor
  - 2 x USB 3.2 Gen 2 (3rd Gen AMD Ryzen) or USB 3.2 Gen1 (2nd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) ports (1x Type-A & 1x Type-C) on the back panel
  - 2 x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
• Audio:
  • Realtek ALC1220 Codec
  • 7.1-Channel High Definition Audio
  • Supports Optical S/PDIF output
• LAN:
• 1 x Realtek 8111H Gigabit LAN Controller
• Internal Connectors:
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x 4-pin ATX 12V power connector
  • 6 x SATA 6Gb/s connectors
  • 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
  • 2 x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
  • 1 x 4-pin CPU fan connector
  • 1 x 4-pin water-pump connector
  • 4 x 4-pin system fan connectors
  • 1 x Front panel audio connector
  • 2 x System panel connectors
  • 1 x TPM module connector
  • 1 x Serial port connector
  • 1 x Clear CMOS jumper
  • 1 x Chassis Intrusion connector
  • 2 x 4-pin RGB LED connectors
  • 2 x 3-pin RAINBOW LED connectors
  • 4 x EZ Debug LEDs
• Back Paner Ports:
  • Keyboard / Mouse
  • USB 3.2 Gen1 Type-A
  • LAN Port
  • HD Audio Connectors
  • Flash BIOS Button
  • USB 2.0 Ports
  • HDMI Port
  • USB 3.2 Gen2 Ports (Type-A + C)
  • USB 3.2 Gen1 Type-A Ports
  • Optical S/PDIF out
• Dimension: 12 in. x 9.6 in. (30.4 cm x 24.3 cm); ATX Form Factor
• Mounting: 9 mounting holes
• Operating System: Support for Windows 10 64-bit
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Available Quantity

5

UPC

824142189627

SKU

mingleX570APRO

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: PRIME X570-P
• CPU: AMD AM4 Socket for 3rd and 2nd  Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
• Chipset: AMD X570
• Memory:
  • 3rd Gen AMD Ryzen Processors
    - 4 x DIMM, max. 128GB, DDR4 4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133  MHz, un-buffered memory
  • 2nd Gen AMD Ryzen Processors
    - 4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133  MHz, un-buffered memory
  • 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133  MHz, un-buffered memory
    - Dual channel memory architecture
    - ECC Memory (ECC mode) support varies by CPU.
    * The maximum memory capacity supported vary depending on the CPU you installed.
• Expansion Slots:
  • 3rd Gen AMD Ryzen Processors
    - 1 x PCI Express 4.0 x16 slot (at x16 mode)
  • 2nd Gen AMD Ryzen Processors
    - 1 x PCI Express 3.0 x16 slot (at x16 mode)
  • 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 1 x PCI Express 3.0 x16 slot (at x8 mode)
  • AMD X570 chipset
    - 1 x PCI Express 4.0 x 16 slot (max. at x4 mode)
    - 3 x PCI Express 4.0 x1 slots
• Graphics:
  • Integrated Graphics in the 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    VGA output support: HDMI port
    Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz
• Multi-GPU Support:
  • 3rd and 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    Supports AMD 2-Way CrossFireX Technology
• Storage:
  • 3rd Gen AMD Ryzen Processors
    - M.2_1 socket 3 with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
  • 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - M.2_1 socket 3 with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
  • AMD X570 Chipset
    - M.2_2 socket 3 with M Key, Type 2242/2260/2280/22110 (PCIE 4.0 x4 and SATA modes) storage devices support
    - 6 x Serial ATA 6.0 Gb/s connectors with RAID 0, RAID 1 and RAID 10 support
• LAN: Realtek 8111H
• Audio:
  • Realtek S1200A  8-channel* high definition audio CODEC
    - Audio shielding: ensures precise analog/digital separation and greatly reduced multi-lateral interference
    - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
    - Premium Japanese audio capacitors: provides warm, natural, and immersive sound with exceptional clarity and fidelity
    - Supports jack-detection and front panel jack-retasking
    * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
• USB:
  • 3rd and 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 2 x USB 3.2 Gen 1 (up to 5Gbps) ports (2 ports at back panel)
    - 2 x USB 3.2 Gen 2 (up to 10Gbps) ports (2 ports at back panel)*
    * The USB ports under the LAN port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD Ryzen Processors.
  • AMD X570 chipset
    - 2 x USB 3.2 Gen 2 (up to 10Gbps) ports (2 ports at back panel)
    - 4 x USB 3.2 Gen 1 (up to 5Gbps) ports (4 ports at mid-board)
    - 5 x USB 2.0 ports (2 ports at back panel, 3 ports at mid-board)
• ASUS Quiet Thermal Solution:
  • ASUS Fan Xpert 4
  • Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan and PCH Heatsink
• Back I/O Ports:
  • 1 x PS/2 keyboard/mouse combo port
  • 1 x HDMI port
  • 1 x LAN (RJ-45) port
  • 4 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A)*
  • 2 x USB 3.2 Gen 1 (up to 5Gbps) ports (Type-A)
  • 2 x USB 2.0/1.1 ports
  • 3 x Audio jacks support 8-channel audio output
  • * The USB ports under the LAN port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD Ryzen Processors .
• Internal connectors:
  • 2 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 4 USB 3.2 Gen 1 ports
  • 2 x USB 2.0/1.1 connectors support additional 3 USB 2.0/1.1 ports
  • 1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280 devices support (both SATA & PCIE mode)
  • 1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280/22110 devices support (both SATA & PCIE mode)
  • 6 x SATA 6.0Gb/s connectors (gray)
  • 1 x CPU Fan header (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) CPU coolers control with auto detection support
  • 1 x AIO Pump header (4-pin)
  • 3 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) coolers control with auto detection support
  • 1 x PCH _FAN connector (4-pin)
  • 2 x Aura RGB headers
  • 1 x Addressable Gen 2 header
  • 1 x COM header
  • 1 x SPI_TPM header
  • 1 x S/PDIF out header
  • 1 x System Panel connector
  • 1 x Front panel audio connector (AAFP)
  • 1 x 24-pin EATX Power connector
  • 1 x 8-pin EATX 12V Power connector
  • 1 x 4-pin EATX 12V Power connector
  • 1 x Clear CMOS jumper
  • 1 x Chassis Intrusion header (layout only)
• BIOS: 256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability: WOL by PME, PXE
• Accessories:
  • 2 x Serial ATA 6.0Gb/s cables
  • 1 x Addressable RGB header extension cable
  • 1 x IO Shield
  • 1 x M.2 screw package
  • 1 x Support DVD
  • 1 x User's Manual
• Support DVD:
  • Drivers
  • ASUS Utilities
  • EZ Update
• Operating System: Windows 10 64-bit
• Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5cm x 24.4cm)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Available Quantity

5

UPC

192876263815

SKU

minglePRIME X570-P

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: X570 EXTREME4
• Unique Feature:
  • ASRock USB 3.2 Gen2
  • ASRock Super Alloy
  • ASRock Steel Slot Gen4
  • ASRock Full Coverage M.2 Heatsink
  • ASRock Hyper M.2 (PCIe Gen4x4 & SATA3)
  • ASRock Ultra USB Power
  • ASRock POST Status Checker (PSC)
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU: Socket AM4
  • Supports AMD AM4 socket Ryzen 2000 and 3000 series processors
  • Intersil Digital PWM
  • 10 Power Phase design
• Chipset: AMD X570
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 4 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 4666+(OC)/4400(OC)/4300(OC)/4266(OC)/4200(OC)/4133(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory
  • AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory
  • AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buffered memory
  • Max. capacity of system memory: 64GB
  • 15 Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO,PERM VDDCR_SOC, +1.8V, VDDP Voltage Multi-adjustment
• Slots:
  • AMD Ryzen series CPUs (Matisse):
    - 2 x PCI Express 4.0 x16 Slots (single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE4))
  • AMD Ryzen series CPUs (Pinnacle Ridge)
    - 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE4))
  • AMD Ryzen series CPUs (Picasso)
    - 2 x PCI Express 3.0 x16 Slots (single at x8 (PCIE1); dual at x8 (PCIE1) / x4 (PCIE4)) Supports NVMe SSD as boot disks
    - 3 x PCI Express 4.0 x1 Slots
    - Supports AMD Quad CrossFireXTM and CrossFireXTM
    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
    - 15 Gold Contact in VGA PCIe Slot (PCIE1)
• Graphics:
  • Integrated AMD RadeonTM Vega Series Graphics in Ryzen Series APU
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB
  • Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) 30Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Ports (Compliant HDMI monitor is required)
  • Supports HDCP 1.4 with HDMI 1.4 Port
  • Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port
  • Supports Microsoft PlayReady
• Storage:
  • 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse)
    or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)
  • 1 x Hyper M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s)*
• Audio:
  • 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
  • Premium Blu-ray Audio support
  • Supports Surge Protection
  • Supports Purity Sound 4
  • Supports DTS Connect
• LAN:
  • Gigabit LAN 10/100/1000 Mb/s
  • GigaLAN Intel I211AT
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE
• Connector:
  • 1x TPM Header
  • 1x SPI TPM Header
  • 1x Power LED and Speaker Header
  • 1x AMD Fan LED Header
  • 1x RGB LED Header
  • 1x Addressable LED Header
  • 1x CPU Fan Connector (4-pin)
  • 1x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
  • 4x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
  • 1x 24 pin ATX Power Connector (Hi-Density Power Connector)
  • 1x 8 pin 12V Power Connector (Hi-Density Power Connector)
  • 1x 4 pin 12V Power Connector (Hi-Density Power Connector)
  • 1x Front Panel Audio Connector (15 Gold Audio Connector)
  • 1x AMD LED Fan USB Header
  • 1x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt AIC Card only)
  • 2x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
  • 2x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)
  • 1x Front Panel Type C USB 3.2 Gen1 Header (Supports ESD Protection)
• Rear Panel I/O:
  • 2x Antenna Ports (on I/O Panel Shield)
  • 1x PS/2 Mouse/Keyboard Port
  • 1x HDMI Port
  • 1x Optical SPDIF Out Port
  • 1x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection)
  • 1x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection)
  • 6x USB 3.2 Gen1 Ports (Supports ESD Protection)
  • 1x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker /Microphone
• Software:
  • ASRock A-Tuning
  • ASRock Polychrome SYNC
  • ASRock XFast LAN
• UEFI:
  • ASRock Full HD UEFI
  • ASRock Instant Flash
  • ASRock Easy RAID Installer
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD
  • 4x SATA Data Cables
  • 3x Screws for M.2 Sockets
  • 2x Standoffs for M.2 Sockets
• Form Factor:
  • ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
  • 2oz Copper PCB
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Available Quantity

5

UPC

Does not apply

SKU

mingleX570 EXTREME4

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: X570 PHANTOM GAMING 4
• Unique Feature:
  • ASRock USB 3.2 Gen2
    - ASRock USB 3.2 Gen2 Type-A Ports (10 Gb/s)
  • ASRock Super Alloy
    - XXL Aluminum Alloy Heatsink
    - Premium 50A Power Choke
    - Sapphire Black PCB
    - High Density Glass Fabric PCB
    - 2oz Copper PCB
  • ASRock Steel Slot Gen4
  • ASRock Hyper M.2 (PCIe Gen4x4 & SATA3)
  • ASRock POST Status Checker (PSC)
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU: Socket AM4
  • Supports AMD AM4 socket Ryzen 2000 and 3000 series processors
  • Digi Power design
  • 10 Power Phase design
• Chipset: AMD Premium X570
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 4 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 4066+(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory
  • AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3466+(OC)/3200(OC)/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory
  • AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buffered memory
  • Max. capacity of system memory: 64GB
  • 15 Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP, VDDG, CPU Load-Line Calibration, CPU VDDCR_SOC Load-Line Calibration Voltage Multi-adjustment
• Slots:
  • AMD Ryzen series CPUs (Matisse)
    - 2 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1);dual at x16 (PCIE1) / x4 (PCIE3))
    AMD Ryzen series CPUs (Pinnacle Ridge)
    - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1);dual at x16 (PCIE1) / x4 (PCIE3))
    AMD Ryzen series CPUs (Picasso)
    - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x8 (PCIE1);dual at x8 (PCIE1) / x4 (PCIE3))
    - 2 x PCI Express 4.0 x1 Slots
    - Supports AMD Quad CrossFireXTM and CrossFireXTM
    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
    - 15 Gold Contact in VGA PCIe Slot (PCIE1)
• Graphics:
  • Integrated AMD RadeonTM Vega Series Graphics in Ryzen Series APU
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB.
  • Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers
  • Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
  • Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Ports (Compliant HDMI monitor is required)
  • Supports HDCP 1.4 with HDMI 1.4 and DisplayPort 1.2 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 1.4 and DisplayPort 1.2 Ports
  • Supports Microsoft PlayReady
• Storage:
  • 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280/22110 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)
  • 1 x Hyper M.2 Socket (M2_3), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)
  • Supports NVMe SSD as boot disks
  • Supports ASRock U.2 Kit
• Audio:
  • 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec)
  • Premium Blu-ray Audio support
  • Supports Surge Protection
  • ELNA Audio Caps
  • PCB Isolate Shielding
  • Individual PCB Layers for R/L Audio Channel
• LAN:
  • Gigabit LAN 10/100/1000 Mb/s
  • Giga PHY Intel I211AT
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE
• Connector:
  • 1 x COM Port Header
  • 1 x TPM Header
  • 1 x SPI TPM Header
  • 1 x Power LED and Speaker Header
  • 2 x RGB LED Headers
  • 1 x Addressable LED Header
  • 1 x CPU Fan Connector (4-pin)
  • 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
  • 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
  • 1 x 24 pin ATX Power Connector
  • 1 x 8 pin 12V Power Connector
  • 1 x Front Panel Audio Connector
  • 1 x AMD LED Fan USB Header
  • 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt AIC Card only)
  • 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
  • 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O:
  • 3 x Antenna Ports (on I/O Panel Shield)
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x HDMI Port
  • 1 x DisplayPort 1.2
  • 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection)
  • 6 x USB 3.2 Gen1 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Line in / Front Speaker / Microphone
• Software:
  • ASRock Phantom Gaming Tuning
  • ASRock Polychrome SYNC
  • ASRock Key Master
  • ASRock XFast LAN
• UEFI:
  • ASRock Full HD UEFI
  • ASRock Instant Flash
  • ASRock Easy RAID Installer
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD, I/O Shield
  • 2 x SATA Data Cables
  • 3 x Screws for M.2 Sockets
• Form Factor:
  • ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm x 22.9 cm
  • Solid Capacitor design
  • 2oz Copper PCB
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Available Quantity

5

UPC

Does not apply

SKU

mingleX570 PHANTOM GAMING 4

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Available Quantity

5

UPC

192876380512

SKU

mingleROG STRIX X570-E GAMING

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Specifications

• Mfr Part Number: B450 AORUS PRO WIFI
• CPU: Socket AM4
  • AMD Ryzen 2nd Generation processors
  • AMD Ryzen with Radeon Vega Graphics processors
  • AMD Ryzen 1st Generation processors
• Chipset: AMD B450

• Memory: 4x DDR4-3200(OC)/ 2933/ 2667/ 2400/ 2133 MHz DIMM Slots, Dual Channel, ECC, Non-ECC, Unbuffered, Max Capacity of 64GB

• Slots: 1x PCI-Express 3.0 x16 Slot, 2x PCI-Express 2.0 x16 Slots (one runs at x4, one runs at x1), 1x PCI-Express 2.0 x1 Slot

• Multi-Graphics: Support for AMD Quad-GPU and 2-Way CrossFireX Technology
• Storage:
  • SATA: 6x SATA3 Ports, Support RAID 0, 1, 10
  • M.2: 2x M.2 Ports (M Key), One supports type 2242/ 2260/ 2280/ 22110 SATA and PCIe 3.0 x4/x2 SSD, One supports type 2242/ 2260/ 2280 PCIe 3.0 x2 SSD

• Audio: Realtek ALC1220-VB 7.1-Channel High Definition Audio CODEC

• LAN: Intel Gigabit Ethernet Controller; Dual-Band 802.11 a/b/g/n/ac Wireless LAN (2.4/5GHz); Bluetooth 4.2

• Ports: 2x USB 3.1 Gen 2 Ports (1 Type-A rear, 1 Type-C rear), 6x USB 3.1 Gen 1 Ports (4 rear, 2 via header), 4x USB 2.0/1.1 Ports (4 via headers), 1x HDMI port, 1x DVI-D port, 1x Optical S/PDIF Out Connector, 2x SMA antenna connectors (1T1R), 1x RJ45 LAN Port, Audio I/O Jacks

• Power Connector: 1x 24-pin ATX Main Power Connector, 1x 8-pin ATX 12V Power Connector
• Form Factor: ATX, 30.5 x 24.4 cm


Available Quantity

5

UPC

889523014349

SKU

mingleB450 AORUS PRO WIFI

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: B450 AORUS ELITE
• CPU: Socket AM4
  • AMD Ryzen 2nd Generation processors
  • AMD Ryzen with Radeon Vega Graphics processors
  • AMD Ryzen 1st Generation processors
• Chipset: AMD B450
• Memory: 4x DDR4-3200(OC)/ 2933/ 2667/ 2400/ 2133 MHz DIMM Slots, Dual Channel, ECC, Non-ECC, Unbuffered, Max Capacity of 64GB

• Slots: 1x PCI-Express 3.0 x16 Slot, 1x PCI-Express 2.0 x16 Slot (runs at x4), 2x PCI-Express 2.0 x1 Slots
• Multi-Graphics: Support for AMD Quad-GPU and 2-Way CrossFireX Technology
• Storage:
  • SATA: 6x SATA3 Ports, Support RAID 0, 1, 10
  • M.2: 2x M.2 Ports (w/ M Key), one supports type 2242/ 2260/ 2280/ 22110 SATA and PCIe 3.0 x4/x2 SSD, one supports type 2242/ 2260/ 2280 PCIe 3.0 x2 SSD

• Audio: Realtek ALC892 7.1-Channel High Definition Audio CODEC
• LAN: Realtek Gigabit Ethernet Controller
• Ports: 6x USB 3.1 Gen 1 Ports (4 rear, 2 via header), 8x USB 2.0/1.1 Ports (4 rear, 4 via headers), 1x PS/2 Keyboard/ Mouse Port, 1x HDMI Port, 1x DVI-D Port, 1x RJ45 LAN Port, Audio I/O Jacks

• Power Connector: 1x 24-pin ATX Main Power Connector, 1x 8-pin ATX 12V Power Connector
• Form Factor: ATX, 30.5 x 23.5 cm


Note

Currently out of stock

Available Quantity

0

UPC

889523014653

SKU

mingleB450 AORUS ELITE

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

Does not apply

SKU

mingleB365M-HDV

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: X570 PHANTOM GAMING 4 WIFI AX
• Unique Feature:
  • ASRock USB 3.2 Gen2
    - ASRock USB 3.2 Gen2 Type-A Ports (10 Gb/s)
  • ASRock Super Alloy
    - XXL Aluminum Alloy Heatsink
    - Premium 50A Power Choke
    - Sapphire Black PCB
    - High Density Glass Fabric PCB
    - 2oz Copper PCB
  • Intel 802.11ax WiFi
  • ASRock Steel Slot Gen4
  • ASRock Hyper M.2 (PCIe Gen4x4 & SATA3)
  • ASRock POST Status Checker (PSC)
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU: Socket AM4
  • Supports AMD AM4 socket Ryzen 2000 and 3000 series processors
  • Digi Power design
  • 10 Power Phase design
• Chipset: AMD X570
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 4 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 4066+(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory*
  • AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory*
  • AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory*
  • Max. capacity of system memory: 128GB**
  • 15μ Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP, VDDG, CPU Load-Line Calibration, CPU VDDCR_SOC Load-Line Calibration Voltage Multi-adjustment
• Slots:
  • AMD Ryzen series CPUs (Matisse)
    - 2 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3))*
  • AMD Ryzen series CPUs (Pinnacle Ridge)
    - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1); dual at x16 (PCIE1) / x4 (PCIE3))*
  • AMD Ryzen series CPUs (Picasso)
    - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x8 (PCIE1); dual at x8 (PCIE1) / x4 (PCIE3))*
    - 2 x PCI Express 4.0 x1 Slots
    - Supports AMD Quad CrossFireX and CrossFireX
    - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
    - 15μ Gold Contact in VGA PCIe Slot (PCIE1)
• Graphics:
  • Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU*
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB.**
  • Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers
  • Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required)
  • Supports HDR (High Dynamic Range) with HDMI 2.0
  • Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.2 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports
  • Supports Microsoft PlayReady
• Storage:
  • 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280/22110 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)*
  • 1 x Hyper M.2 Socket (M2_3), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)*
• Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec)
• LAN:
  • Gigabit LAN 10/100/1000 Mb/s
  • GigaLAN Intel I211AT
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE.
• Wireless LAN:
  • Intel 802.11ax WiFi Module
  • Supports IEEE 802.11a/b/g/n/ax
  • Supports Dual-Band (2.4/5 GHz)
  • Supports high speed wireless connections up to 2.4Gbps
  • 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  • Supports Bluetooth 5.0 + High speed class II
  • Supports MU-MIMO
• Connector:
  • 1 x COM Port Header
  • 1 x SPI TPM Header
  • 1 x Power LED and Speaker Header
  • 2 x RGB LED Headers*
  • 1 x Addressable LED Header**
  • 1 x CPU Fan Connector (4-pin)***
  • 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  • 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****
  • 1 x 24 pin ATX Power Connector
  • 1 x 8 pin 12V Power Connector
  • 1 x Front Panel Audio Connector
  • 1 x AMD LED Fan USB Header
  • 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt AIC Card only)
  • 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
  • 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O:
  • 3 x Antenna Ports (on I/O Panel Shield)
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x HDMI Port
  • 1 x DisplayPort 1.2
  • 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection)
  • 6 x USB 3.2 Gen1 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Line in / Front Speaker / Microphone
• Software:
  • ASRock Polychrome SYNC
  • ASRock Key Master
  • ASRock XFast LAN
• UEFI:
  • ASRock Full HD UEFI
  • ASRock Instant Flash
  • ASRock Easy RAID Installe
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbarr
• Accessories:
  • Quick Installation Guide, Support CD, I/O Shield
  • 2 x SATA Data Cables
  • 2 x SMA WiFi Antenna Cables
  • 1 x ASRock WiFi 2.4/5 GHz Antenna
  • 2 x Screws for M.2 Sockets
• Hardware Monitor:
  • Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans
  • Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans
  • Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, PREM VDDCR_SOC, +1.8V, VDDP
• Form Factor:
  • ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm x 22.9 cm
  • Solid Capacitor design
  • 2oz Copper PCB
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Note

Currently out of stock

Available Quantity

0

UPC

Does not apply

SKU

mingleX570 PHANTOM GAMING 4 WIFI AX

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: X570 GAMING X
• Unique Features:
  • Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    - @BIOS
    - AutoGreen
    - Cloud Station
    - EasyTune
    - Fast Boot
    - Game Boost
    - ON/OFF Charge
    - RGB Fusion
    - Smart Backup
    - Smart Keyboard
    - Smart Survey
    - System Information Viewer
    - USB Blocker
  • Support for Q-Flash Plus
  • Support for Q-Flash
  • Support for Xpress Install
• CPU: AMD Socket AM4,support for: 3rd Generation AMD Ryzen processors/ 2nd Generation AMD Ryzen processors/ 2nd Generation AMD Ryzen with Radeon Vega Graphics processors/ AMD Ryzen with Radeon Vega Graphics processors
• Chipset: AMD X570
• Memory:
  • 3rd Generation AMD Ryzen processors:Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
  • 2nd Generation AMD Ryzen processors/AMD Ryzen with Radeon Vega Graphics processors:Support for DDR4 2933/2667/2400/2133 MHz memory modules: Support for DDR4 2933/2667/2400/2133 MHz memory modules
  • 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
  • Dual channel memory architecture
  • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
  • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  • Support for Extreme Memory Profile (XMP) memory modules
• Expension Slots:
  • Integrated in the CPU (PCIEX16):
    1. 3rd Generation AMD Ryzen processors:
    - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
    2. 2nd Generation AMD Ryzen processors:
    - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
    * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    3. 2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors:
    - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 Integrated in the Chipset (PCIEX4/PCIEX1)
    - 1 x PCI Express x16 slot, supporting PCIe 4.0*/3.0 and running at x4 (PCIEX4)
    * For 3rd Generation AMD Ryzen processors only.
    - 3 x PCI Express x1 slots, supporting PCIe 4.0*/3.0
    * For 3rd Generation AMD Ryzen processors only.
• Multi-Graphics:
  • Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
  • Note: For 3rd Generation AMD Ryzen processors/2nd Generation AMD Ryzen processors only.
• Onboard Graphics:
  • Integrated Graphics Processor:
    - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
    * Support for HDMI 2.0 version, HDCP 2.2, and HDR.
  • Maximum shared memory of 16 GB
  • Note: For 2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors only.
• Storage:
  • Integrated in the CPU (M2A_SOCKET):
    1. 3rd Generation AMD Ryzen processors:
    - 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support)
    2. 2nd Generation AMD Ryzen processors/2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors:
    - 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)
  • Integrated in the Chipset (M2B_SOCKET):
    - 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0*/3.0 x4/x2 SSD support)
    * For 3rd Generation AMD Ryzen processors only.
    - 6 x SATA 6Gb/s connectors
    - Support for RAID 0, RAID 1, and RAID 10
• Audio:
  • Realtek ALC887 codec
  • High Definition Audio
  • 2/4/5.1-channel
• LAN: Realtek GbE LAN chip (10/100/1000 Mbit)
• USB:
  • Integrated in the CPU:
    - 4 x USB 3.2 Gen 1 ports on the back panel
  • Chipset:
    - 4 x USB 3.2 Gen 1 ports available through the internal USB headers
    - 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
• Internal I/O Connectors:
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x CPU fan header
  • 1 x water cooling CPU fan header
  • 2 x system fan headers
  • 1 x CPU cooler LED strip/RGB LED strip header
  • 2 x addressable LED strip headers
  • 2 x RGB LED strip headers
  • 6 x SATA 6Gb/s connectors
  • 2 x M.2 Socket 3 connectors
  • 1 x front panel header
  • 1 x front panel audio header
  • 2 x USB 3.2 Gen 1headers
  • 2 x USB 2.0/1.1 headers
  • 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
  • 1 x Clear CMOS jumper
  • 1 x Q-Flash Plus button
• Back Panel Connectors:
  • 1 x PS/2 keyboard port
  • 1 x PS/2 mouse port
  • 1 x HDMI port
  • 4 x USB 3.2 Gen 1 ports
  • 2 x USB 2.0/1.1 ports
  • 1 x RJ-45 port
  • 3 x audio jacks
• I/O Controller: iTE I/O Controller Chip
• H/W Monitoring:
  • Voltage detection
  • Temperature detection
  • Fan speed detection
  • Water cooling flow rate detection
  • Overheating warning
  • Fan fail warning
  • Fan speed control (Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.)
• BIOS:
  • 1 x 128 Mbit flash
  • Use of licensed AMI UEFI BIOS
  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Bundled Software:
  • Norton Internet Security (OEM version)
  • Realtek 8118 Gaming LAN Bandwidth Control Utility
• Operating System: Support for Windows 10 64-bit
• Form Factor: ATX Form Factor; 30.5cm x 24.4cm
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Note

Currently out of stock

Available Quantity

0

UPC

889523018026

SKU

mingleX570 GAMING X

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: TUF GAMING X570-PLUS (WI-FI)
• CPU: AMD AM4 Socket for 3rd and 2nd  Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
• Chipset: AMD X570
• Memory:
  • AMD Ryzen 3rd Generation Processors
    - 4 x DIMM, max. 128GB, DDR4 4400(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
  • AMD Ryzen 2nd Generation Processors
    - 4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
  • AMD Ryzen 2nd and 1st Generation with Radeon Vega Graphics Processors
    - 4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
    - Dual channel memory architecture
    - ECC Memory (ECC mode) support varies by CPU.
• Expansion Slots:
  • AMD Ryzen 3rd Generation Processors
    - 1 x PCIe 4.0 x16 (x16 mode)
  • AMD Ryzen 2nd Generation Processors
    - 1 x PCIe 3.0 x16 (x16 mode)
  • AMD Ryzen 2nd and 1st Generation with Radeon Vega Graphics Processors
    - 1 x PCIe 3.0/2.0 x16 (x8 mode)
  • AMD X570 chipset
    - 1 x PCIe 4.0 x16 (max at x4 mode)
    - 2 x PCIe 4.0 x1
• Graphics:
  • Integrated Graphics in the 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors Multi-VGA output support: HDMI/DisplayPort ports
    - Supports HDMI1.4b with max. resolution 4096 x 2160@24Hz
    - Supports DisplayPort with max. resolution 4096 x 2160@60Hz
• Multi-GPU Support:
  • 3rd and 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - Supports AMD 2-Way CrossFireX Technology
• Storage:
  • 3rd Gen AMD Ryzen Processors:
    - 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 4.0 x 4 mode)
  • 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
  • AMD X570 chipset :
    - 1 x M.2_2 socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 4.0 x 4 mode)
    - 8 x SATA 6Gb/s port(s)
    - Support Raid 0, 1, 10
• LAN:
  • Realtek L8200A
  • ASUS Turbo LAN Utility
  • TUF LANGuard
• Wireless:

  • Intel Wireless-AC 9260
  • 2x2 Wi-Fi 5(802.11 a/b/g/n/ac) with MU-MIMO support dual frequency band 2.4/5 GHz
  • Supports channel bandwidth: HT20/HT40/HT80/HT160
• Bluetooth: Bluetooth 5.0
• Audio:
  • Realtek S1200A 8-channel high definition audio CODEC
    - Exclusive DTS Custom for GAMING Headsets
    - Audio Shielding: Ensures precision analog/digital separation and greatly reduces multi-lateral interference
    - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
    - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity.
    - Supports jack-detection and front panel jack-retasking
    - Audio Cover: Effective shielding preserves the integrity of audio signals to ensure best quality.
• USB:
  • 3 x USB 3.2 Gen 2 ports (up to 10Gbps) at back panel(2*Type A, 1*Type C)
  • 6 x USB 3.2 Gen 1 ports (2 ports @mid-board, 4 ports @back panel)
  • 4 x USB 2.0 ports at mid-board
• Back I/O Ports:
  • 1 x DisplayPort port
  • 1 x HDMI port
  • 1 x PS/2 combo port
  • 1 x LAN (RJ45) port
  • 1 x 2x2 WI-FI module
  • 3 x USB 3.2 Gen 2 ports (2*Type-A, 1*Type-C)
  • 4 x USB 3.2 Gen 1 ports
  • 5 x Audio jacks + 1 x Optical S/PDIF out
• Internal connectors:
  • 1 x USB 3.2 Gen 1 connectors support additional 2 USB ports (19-pin)
  • 2 x USB 2.0 connectors support additional 4 USB ports
  • 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 4.0/3.0 x 4 mode)
  • 1 x M.2_2 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 4.0 x 4 mode)
  • 8 x SATA 6.0Gb/s connectors
  • 1 x Addressable RGB Header(s)
  • 2 x RGB Header(s)
  • 1 x CPU Fan connector (support DC/PWM mode)
  • 1 x CPU OPT Fan connector (1 x 4 -pin)
  • 1 x AIO_Pump header (4-pin)
  • 3 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) coolers control
  • 1 x Front panel audio connector (AAFP)
  • 1 x 24-pin EATX Power connector
  • 1 x 8-pin EATX 12V Power connector
  • 1 x 4-pin EATX 12V Power connector
  • 1 x System Panel*
  • 1 x COM port
  • 1 x SPI_TPM header (14-1pin)
  • 1 x Clear CMOS jumper
• BIOS: 256Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, F4 AURA ON/OFF, Last Modified log, F9 Search, F12 PrintScreen,  and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability: WOL by PME, PXE
• Accessories:
  • 2 x SATA 6Gb/s cables
  • 1 x IO Shield
  • 1 x M.2 Screw Package
  • 1 x Support DVD
  • 1 x TUF Gaming Sticker
  • 1 x TUF Certification card(s)
  • 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
  • 1 x User's manual
• Support DVD:
  • Drivers
  • ASUS Utilities
  • ASUS EZ Update
  • Anti-virus software (OEM version)
• Operating System: Windows 10 64-bit
• Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5cm x 24.4cm)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Note

Currently out of stock

Available Quantity

0

UPC

192876388495

SKU

mingleTUF GAMING X570-PLUS (WI-FI)

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: PRIME X570-PRO
• CPU: AMD AM4 Socket for 3rd and 2nd  Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
• Chipset: AMD X570
• Memory:
  • 3rd Gen AMD Ryzen Processors
    - 4 x DIMM, max. 128GB, DDR4 4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133  MHz, un-buffered memory
  • 2nd Gen AMD Ryzen Processors
    - 4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133  MHz, un-buffered memory
  • 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133  MHz, un-buffered memory
  • Dual channel memory architecture
  • ECC Memory (ECC mode) support varies by CPU.
  • *The maximum memory capacity supported vary depending on the CPU you installed.
• Expansion Slots:
  • 3rd Gen AMD Ryzen Processors
    - 2 x PCI Express 4.0 x16 slots (single at x16 or dual at x8/x8 mode)
  • 2nd Gen AMD Ryzen Processors
    - 2 x PCI Express 3.0 x16 slots (single at x16 or dual at x8/x8 mode)
  • 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 1 x PCIe 3.0 x16 slot (x8 mode)
  • AMD X570 chipset
    - 1 x PCI Express 4.0 x 16 slot (max. at x4 mode)
    - 3 x PCI Express 4.0 x1 slots
• Graphics:
  • Integrated Graphics in the 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    Multi-VGA output support: DisplayPort/HDMI ports
    Supports DisplayPort 1.2 with max. resolution of 4096 x 2160 @60Hz
    Supports HDMI 2.0b with max. resolution of 4096 x 2160 @60Hz
• Multi-GPU Support:
  • 3rd and 2nd Gen AMD Ryzen Processors
    - Supports NVIDIA 2-Way SLI Technology
    - Supports AMD 3-Way CrossFireX Technology
  • 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - Supports AMD 2-Way CrossFireX Technology
• Storage:
  • 3rd Gen AMD Ryzen Processors
    - M.2_1 socket 3 with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
  • 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - M.2_1 socket 3 with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
  • AMD X570 Chipset:
    - M.2_2 socket 3 with M Key, Type 2242/2260/2280/22110 (PCIE 4.0 x 4 and SATA modes) storage devices support
    - 6 x Serial ATA 6.0 Gb/s connectors with RAID 0, RAID 1 and RAID 10 support
• LAN: Intel I211-AT Gigabit LAN
• Audio:
  • Realtek S1220A 8-channel high definition audio CODEC featuring Crystal Sound 3
    - Separate layer for left and right track, ensuring both sound deliver equal quality
    - Impedance sense for front and rear headphone outputs
    - Audio shielding ensures precise analog/digital separation and greatly reduced multi-lateral interference
    - EMI protection cover to prevent electrical noise to affect the amplifier quality
    - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
    - Premium Japanese audio capacitors provides warm, natural, and immersive sound with exceptional clarity and fidelity
    - High quality 120dB SNR stereo playback output (Line-out@back) & 113dB SNR input (Line-in) support
    - Supports up to 32-Bit/192kHz playback*
    - Supports jack-detection, multi-streaming, front panel jack-retasking (MIC)
    - Optical S/PDIF out port at back I/O
    * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
• USB:
  • 3rd and 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 4 x USB 3.2 Gen 1(up to 5Gbps) ports (4 ports at back panel)
  • AMD X570 chipset
    - 1 x USB 3.2 Gen 2 (up to 10Gbps) front connector
    - 4 x USB 3.2 Gen 2 (up to 10Gbps) ports (3*Type A+1*Type C at back panel)
    - 2 x USB 3.2 Gen 1 (up to 5Gbps) ports (2 ports at mid-board)
    - 4 x USB 2.0 ports at mid-board
• ASUS Quiet Thermal Solution:
  • ASUS Fan Xpert 4
  • Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan,PCH and M.2 Heatsink
• Back I/O Ports:
  • 1 x PS/2 keyboard/mouse combo port
  • 1 x DisplayPort
  • 1 x HDMI port
  • 1 x Intel LAN (RJ45) port
  • 3 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A)
  • 1 x USB 3.2 Gen 2 (up to 10Gbps) port (Type-C)
  • 4 x USB 3.2 Gen 1 (up to 5Gbps) ports (Type-A)
  • 1 x Optical S/PDIF out
  • 5 x Audio Jacks(Line in,Front Speaker Out,Mic in,Center/Subwoofer,Rear Speaker Out)
• Internal connectors:
  • 1 x USB 3.2 Gen 2 (up to 10Gbps) connector
  • 1 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports
  • 2 x USB 2.0 connectors support additional 4 USB ports
  • 1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280/22110 devices support, (both SATA & PCIE mode)
  • 1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280/22110 devices support, (both SATA & PCIE mode)
  • 6 x SATA 6.0Gb/s connectors (gray)
  • 1 x CPU Fan header (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) CPU coolers control with auto detection support
  • 1 x CPU OPT Fan header (4-pin)
  • 1 x AIO Pump header (4-pin)
  • 1 x W_PUMP+ header (4-pin)
  • 1 x PCH _FAN connector (4-pin)
  • 3 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) coolers control with auto detection support
  • 2 x Aura RGB headers
  • 1 x addressable Gen 2 header
  • 1 x Front panel audio connector (AAFP)
  • 1 x SPI_TPM connector
  • 1 x COM connector
  • 1 x 24-pin EATX Power connector
  • 1 x 8-pin EATX 12V Power connector
  • 1 x 4-pin EATX 12V Power connector
  • 1 x System Panel Connector
  • 1 x Clear CMOS header
  • 1 x Node Connector
  • 1 x Power-on button
  • 1 x T_Sensor Header
• BIOS: 256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen,F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information.
• Manageability: WOL by PME, PXE
• Dimesion:
  • Product (mm): L 305*W 244*H 1.2mm
  • Color box(mm): L 326*W 274*H 68mm
• Weight:
  • Product: 0.967KG
  • Color box: 1.52KG
• Accessories:
  • 2 x Serial ATA 6.0Gb/s cables
  • 1 x ASUS Q-connector
  • 1 x Support DVD
  • 1 x 2-in-1 M.2 screws package
  • 1 x Extension cable for Addressable LED
  • 1 x user's manual
• Support DVD:
  • Drivers
  • ASUS Utilities
  • EZ Update
• Operating System: Windows 10 64-bit
• Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5cm x 24.4cm)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Note

Currently out of stock

Available Quantity

0

UPC

192876254011

SKU

minglePRIME X570-PRO

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: X570GPCARBWIFI (MPG X570 GAMING PRO CARBON WIFI)
• CPU: Supports 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Desktop Processors for Socket AM4
• Chipset: AMD X570 Chipset
• Memory:
  • 4x DDR4 memory slots, support up to 128GB, Supports 1866/ 2133/ 2400/ 2666Mhz by JEDEC
  • Dual channel memory architecture
  • Supports non-ECC UDIMM memory
  • Supports ECC UDIMM memory (non-ECC mode)
  • Supports un-buffered memory
• Expansion Slots:
  • 1x PCIe 4.0/3.0 x16 slot (PCI_E1): 3rd Gen AMD Ryzen support PCIe 4.0 x16 mode; 2nd Gen AMD Ryzen support PCIe 3.0x16 mode; Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics support PCIe 3.0 x8 mode
  • 1x PCIe 4.0/ 3.0 x4 slot (PCI_E3)
  • 2x PCIe 3.0 x1 slots
• Onboard Graphics: 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 24Hz
• Multi-Graphics: Supports 2-Way AMD CrossFire Technology
• Storage:
  • AMD X570 Chipset:
    - 6x SATA 6Gb/s ports
    - 2x M.2 slots (Key M): M2_1 slot(from AMD Processor): supports PCIe 4.0 x4 (3rd Gen AMD Ryzen Desktop Processors) or PCIe 3.0 x4 (2nd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) 2242/2260/2280 storage devices; M2_2 slot (from AMD X570 Chipset): supports PCIe 4.0 x4 (3rd Gen AMD Ryzen) or 3.0 x4 (2nd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) and SATA 6Gb/s 2242/ 2260/ 2280/ 22110 storage devices
• RAID: AMD X570 Chipset Supports RAID 0, RAID 1 and RAID 10
• USB:
  • AMD X570 Chipset:
    - 2x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) Type-A ports on the back panell
    - 4x USB 3.2 Gen1 (SuperSpeed USB) ports available through the internal USB 3.2 Gen1 connector
    - 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
  • AMD Processor:
    - 2x USB 3.2 Gen2 (3rd Gen AMD Ryzen) or USB 3.2 Gen1 (2nd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) Type-A and Type-C port on the back panel
    - 2x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
• Audio:
  • Realtek ALC1220 Codec
  • 7.1-Channel High Definition Audio
  • Supports Optical S/PDIF output
• LAN: 1x Intel I211AT Gigabit LAN controller
• Wifi & Bluetooth:
  • Intel Wi-Fi 6 AX200
  • The Wireless module is pre-install in the M2_WIFI1 (Key-E) slot
  • Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
  • Supports Bluetooth 5
• Internal Connectors:
  • 1x 24-pin ATX main power connector
  • 1x 8-pin ATX 12V power connector
  • 1x 4-pin ATX 12V power connector
  • 6x SATA 6Gb/s connectors
  • 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
  • 2x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
  • 1x 4-pin CPU fan connector
  • 1x 4-pin water-pump connector
  • 4x 4-pin system fan connectors
  • 1x Front panel audio connector
  • 2x System panel connectors
  • 1x TPM module connector
  • 1x Clear CMOS jumper
  • 1x Chassis Intrusion connector
  • 1x 4-pin RGB LED connector
  • 2x 3-pin RAINBOW LED connectors
  • 1x 3-pin CORSAIR connector
  • 1x 2-pin LED Demo Connect
  • 4x EZ Debug LEDs
• Back Paner Ports:
  • Keyboard / Mouse
  • USB 3.2 Gen1 Type-A
  • Wireless / Bluetooth
  • LAN
  • Audio Connectors
  • Flash BIOS Button
  • USB 2.0
  • HDMI
  • USB 3.2 Gen2 Type-A + C
  • USB 3.2 Gen2 Type-A
  • Optical S/PDIF out
• Dimension: 12 in. x 9.6 in. (30.4 cm x 24.3 cm); ATX Form Factor
• Mounting: 9 mounting holes
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers
• Operating System: Support for Windows 10 64-bit

Note

Currently out of stock

Available Quantity

0

UPC

824142189511

SKU

mingleX570GPCARBWIFI

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

Does not apply

SKU

mingleX570 PRO4

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: X570 PHANTOM GAMING-ITX/TB3
• Unique Feature:
  • ASRock USB 3.2 Gen2
    - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)
    - ASRock Thunderbolt 3 Type C USB 3.2 Gen2 Port (40Gb/s for Thunderbolt protocol; 10 Gb/s for USB3.2 protocol)
  • ASRock Super Alloy
    - Premium 60A Power Choke
    - 60A Dr.MOS
    - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
    - I/O Armor
    - Matte Black PCB
    - High Density Glass Fabric PCB
    - 2oz Copper PCB

  • Intel 802.11ax WiFi
  • ASRock Steel Slot Gen4
  • ASRock Hyper M.2 (PCIe Gen4x4)
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU:
  • Supports AMD AM4 socket Ryzen 2000 and 3000 series processors
  • Intersil Digital PWM
  • 10 Power Phase design
• Chipset: AMD X570
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 2 x DDR4 DIMM Slots
  • AMD Ryzen series CPUs (Matisse) support DDR4 4533+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory*
  • AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933/2667/2400/2133 ECC & non-ECC, un-buffered memory*
  • AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory*
  • Max. capacity of system memory: 64GB**
  • 15 Gold Contact in DIMM Slots
• BIOS:
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • Supports "Plug and Play"
  • ACPI 5.1 compliance wake up events
  • Supports jumperfree
  • SMBIOS 2.3 support
  • CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP Voltage Multi-adjustment
• Slots:
  • AMD Ryzen series CPUs (Matisse)
    - 1 x PCI Express 4.0 x16 Slot (PCIE1: x16 mode)*
  • AMD Ryzen series CPUs (Pinnacle Ridge)
    - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
  • AMD Ryzen series CPUs (Picasso)
    - 1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)*
    - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ax module (on the rear I/O)
    - 15 Gold Contact in VGA PCIe Slot (PCIE1)
• Graphics:
  • Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU*
  • DirectX 12, Pixel Shader 5.0
  • Shared memory default 2GB. Max Shared memory supports up to 16GB.**
  • Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
  • Supports DisplayPort 1.4 Input with max. resolution up to 4K x 2K (4096x2160) @ 60Hz***
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required)
  • Supports HDR (High Dynamic Range) with HDMI 2.0
  • Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.4 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.4 Ports
  • *Actual support may vary by CPU
    **The Max shared memory 16GB requires 32GB system memory installed.
    ***DisplayPort 1.4 Input is used to connect a Type-C Monitor.
• Storage:
  • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • 1 x Hyper M.2 Socket, supports M Key type 2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)*
• Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
• LAN:
  • Gigabit LAN 10/100/1000 Mb/s
  • GigaLAN Intel I211AT
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE.
• Wireless LAN:
  • Intel 802.11ax WiFi Module
  • Supports IEEE 802.11a/b/g/n/ax
  • Supports Dual-Band (2.4/5 GHz)
  • Supports WiFi6 802.11ax (2.4Gbps)
  • 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  • Supports Bluetooth 5.0 + High speed class II
  • Supports MU-MIMO
• Connector:
  • 1 x SPI TPM Header
  • 1 x RGB LED Header*
  • 1 x Addressable LED Header**
  • 1 x CPU Fan Connector (4-pin)***
  • 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
  • 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*****
  • 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  • 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
  • 1 x Front Panel Audio Connector (15 Gold Audio Connector)
  • 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
  • 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O:
  • 2 x Antenna Ports (on I/O Panel Shield)
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x HDMI Port
  • 1 x DisplayPort 1.4 Input
  • 1 x Optical SPDIF Out Port
  • 1 x USB 3.2 Gen2 Thunderbolt Type-C Port (40Gb/s for Thunderbolt protocol; 10 Gb/s for USB3.2 protocol) (Supports ESD Protection)
  • 2 x USB 3.2 Gen2 Type-A Ports (Supports ESD Protection)
  • 2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • 1 x Clear CMOS Button
  • HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)
• Software:
  • ASRock Phantom Gaming Tuning
  • ASRock Polychrome SYNC
  • ASRock Key Master
  • ASRock XFast LAN
• UEFI:
  • ASRock Full HD UEFI
  • ASRock Instant Flash
  • ASRock Easy RAID Installer
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD
  • 2 x SATA Data Cables
  • 1 x ASRock WiFi 2.4/5 GHz Antenna
  • 1 x Screw for M.2 Socket
• Hardware Monitor:
  • Temperature Sensing: CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Tachometer: CPU/Water Pump, Chassis/Water Pump Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Multi-Speed Control: CPU/Water Pump, Chassis/Water Pump Fans
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, VPPM, PREM VDDCR_SOC, +1.8V, VDDP
• Form Factor:
  • Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
  • 2oz Copper PCB
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Note

Currently out of stock

Available Quantity

0

UPC

Does not apply

SKU

mingleX570 PHANTOM GAMING-ITX/TB3

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

824142187821

SKU

mingleX570GODLIKE

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: H310CM-HDV/M.2
• Unique Feature:
  • ASRock Super Alloy
    - Sapphire Black PCB
    - High Density Glass Fabric PCB
  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop
• CPU:
  • Supports 9th and 8th Gen Intel Core Processors (Socket 1151)
  • Supports CPU up to 95W
  • 4 Power Phase design
  • Supports Intel Turbo Boost 2.0 Technology
• Chipset: Intel H310
• Memory:
  • Dual Channel DDR4 Memory Technology
  • 2 x DDR4 DIMM Slots
  • Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
  • Max. capacity of system memory: 32GB*
  • Supports Intel Extreme Memory Profile (XMP) 2.0
  • 15μ Gold Contact in DIMM Slots
• BIOS:
  • 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  • ACPI 6.0 Compliant wake up events
  • SMBIOS 2.7 Support
  • CPU, GT_CPU, DRAM, PCH 1.05V Voltage Multi-adjustment
• Slots:
  • 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
  • 2 x PCI Express 2.0 x1 Slots
    *Supports NVMe SSD as boot disks
• Graphics:
  • Supports Intel UHD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel UHD Graphics
  • DirectX 12
  • HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
  • Three graphics output options: D-Sub, DVI-D and HDMI**
  • Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
  • Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
  • Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
  • Supports HDCP 2.2 with DVI-D and HDMI 1.4 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port
    *Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
    **Supports up to 2 displays simultaneously
• Storage:
  • 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug*
  • 1 x M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x4 (20 Gb/s)**
    *If M2_1 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled.
    **Supports NVMe SSD as boot disks
    **Supports ASRock U.2 Kit
• Audio:
  • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
  • Supports Surge Protection
  • ELNA Audio Caps
    *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
• LAN:
  • Gigabit LAN 10/100/1000 Mb/s
  • Giga PHY Intel I219V
  • Supports Wake-On-LAN
  • Supports Lightning/ESD Protection
  • Supports Energy Efficient Ethernet 802.3az
  • Supports PXE
• Connector:
  • 1 x Print Port Header
  • 1 x COM Port Header
  • 1 x TPM Header
  • 1 x Chassis Intrusion and Speaker Header
  • 1 x CPU Fan Connector (4-pin)*
  • 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
  • 1 x 24 pin ATX Power Connector
  • 1 x 8 pin 12V Power Connector
  • 1 x Front Panel Audio Connector
  • 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
  • 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)***
• Rear Panel I/O:
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x D-Sub Port
  • 1 x DVI-D Port
  • 1 x HDMI Port
  • 4 x USB 2.0 Ports (Supports ESD Protection)
  • 2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Line in / Front Speaker / Microphone
• Software:
  • ASRock A-Tuning
  • ASRock XFast LAN
• UEFI:
  • ASRock EZ Mode
  • ASRock Full HD UEFI
  • ASRock My Favorites in UEFI
  • ASRock Instant Flash
  • ASRock Internet Flash
• Hardware Monitor:
  • Temperature Sensing: CPU, Chassis/Water Pump Fans
  • Fan Tachometer: CPU, Chassis/Water Pump Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans
  • Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans
  • CASE OPEN detection
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V
• Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories:
  • Quick Installation Guide, Support CD, I/O Shield
  • 2 x SATA Data Cables
  • 1 x Screw for M.2 Socket
• Form Factor:
  • Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
  • Solid Capacitor design
• OS: Microsoft Windows 10 64-bit
• Certifications:
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers

Note

Currently out of stock

Available Quantity

0

UPC

Does not apply

SKU

mingleH310CM-HDV/M.2

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: TUF GAMING X570-PLUS
• CPU: AMD AM4 Socket for 3rd and 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
• Chipset: AMD X570
• Memory:
  • AMD Ryzen 3rd Generation Processors
    - 4 x DIMM, max. 128GB, DDR4 4400(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
  • AMD Ryzen 2nd Generation Processors
    - 4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
  • AMD Ryzen 2nd and 1st Generation with Radeon Vega Graphics Processors
    - 4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
    - Dual channel memory architecture
    - ECC Memory (ECC mode) support varies by CPU..
• Expansion Slots:
  • AMD Ryzen 3rd Generation Processors
    - 1 x PCIe 4.0 x16 (x16 mode)
  • AMD Ryzen 2nd Generation Processors
    - 1 x PCIe 3.0 x16 (x16 mode)
  • AMD Ryzen 2nd and 1st Generation with Radeon Vega Graphics Processors
    - 1 x PCIe 3.0/2.0 x16 (x8 mode)
  • AMD X570 chipset
    - 1 x PCIe 4.0 x16 (max at x4 mode)
    - 3 x PCIe 4.0 x1
• Graphics:
  • Integrated Graphics in the 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors Multi-VGA output support: HDMI/DisplayPort ports
    - Supports HDMI1.4b with max. resolution 4096 x 2160@24Hz
    - Supports DisplayPort with max. resolution 4096 x 2160@60Hz
• Multi-GPU Support:
  • 3rd and 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - Supports AMD 2-Way CrossFireX Technology
• Storage:
  • 3rd Gen AMD Ryzen Processors:
    - 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 4.0 x 4 mode)
  • 2nd Gen AMD Ryzen/2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
    - 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
  • AMD X570 chipset :
    - 1 x M.2_2 socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 4.0 x 4 mode)
    - 8 x SATA 6Gb/s port(s)
    - Support Raid 0, 1, 10
• LAN:
  • Realtek L8200A
  • ASUS Turbo LAN Utility
  • TUF LANGuard
• Audio:
  • Realtek S1200A 8-channel high definition audio CODEC
    - Exclusive DTS Custom for GAMING Headsets
    - Audio Shielding: Ensures precision analog/digital separation and greatly reduces multi-lateral interference
    - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
    - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity.
    - Supports jack-detection and front panel jack-retasking
    - Audio Cover: Effective shielding preserves the integrity of audio signals to ensure best quality.
• USB:
  • 3 x USB 3.2 Gen 2 ports (up to 10Gbps) at back panel(2*Type A, 1*Type C)
  • 6 x USB 3.2 Gen 1 ports (2 ports @mid-board, 4 ports @back panel)
  • 4 x USB 2.0 ports at mid-board
• Back I/O Ports:
  • 1 x DisplayPort port
  • 1 x HDMI port
  • 1 x PS/2 combo port
  • 1 x LAN (RJ45) port
  • 3 x USB 3.2 Gen 2 ports (2*Type-A, 1* Type-C)
  • 4 x USB 3.2 Gen 1 ports
  • 5 x Audio jacks + 1 x Optical S/PDIF out
• Internal connectors:
  • 1 x USB 3.2 Gen 1 connectors support additional 2 USB ports (19-pin)
  • 2 x USB 2.0 connectors support additional 4 USB ports
  • 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 4.0/3.0 x 4 mode)
  • 1 x M.2_2 socket 3 with M key, type 2242/2260/2280/ 22110 storage devices support (SATA & PCIE 4.0 x 4 mode)
  • 8 x SATA 6.0Gb/s connectors
  • 1 x Addressable RGB Header(s)
  • 2 x RGB Header(s)
  • 1 x CPU Fan connector (support DC/PWM mode)
  • 1 x CPU OPT Fan connector (1 x 4 -pin)
  • 1 x AIO_Pump header (4-pin)
  • 3 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) coolers control
  • 1 x Front panel audio connector (AAFP)
  • 1 x 24-pin EATX Power connector
  • 1 x 8-pin EATX 12V Power connector
  • 1 x 4-pin EATX 12V Power connector
  • 1 x System Panel*
  • 1 x COM port
  • 1 x SPI_TPM header (14-1pin)
  • 1 x Clear CMOS jumper
• BIOS: 256Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, F4 AURA ON/OFF, Last Modified log, F9 Search, F12 PrintScreen,  and ASUS DRAM SPD (Serial Presence Detect) memory information
• Manageability: WOL by PME, PXE
• Accessories:
  • 2 x SATA 6Gb/s cables
  • 1 x IO Shield
  • 1 x M.2 Screw Package
  • 1 x Support DVD
  • 1 x TUF Gaming Sticker
  • 1 x TUF Certification card(s)
  • 1 x User's manual
• Support DVD:
  • Drivers
  • ASUS Utilities
  • ASUS EZ Update
  • Anti-virus software (OEM version)
• Operating System: Windows 10 64-bit
• Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5cm x 24.4cm)
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers
