Item TP-Link RE200 AC750 Dual Band WiFi Range Extender
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $35.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: RE200
- Features:
- Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly
- Compatible with 802.11 b/g/n and 802.11ac WiFi devices
- 300Mbps 2.4GHz wireless rate + 5GHz 433Mbps wireless data rates ideal for video streaming, online gaming and internet calling
- High speed mode limits connection to one band (2.4GHz or 5GHz) to offers maximum performance.
- Miniature size and wall-mounted design make it easy to deploy and move flexibly
- Easy configuration by just pushing 'RE' button on the range extender and WPS button on your router
- Smart Signal Indicator Light help to find the right location to place the range extender
- Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
- Supports domain name-based login (http://tplinkextender.net) for advanced management
- Advanced 64/128/152-bit WEP, WPA-PSK / WPA2-PSK encryptions protect your network from security threats
- Hardware Features:
- Standards and Protocols: IEEE802.11ac,IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Interface: 1x 10/100M Ethernet Port (RJ45)
- Plug Type: EU, UK, US, AU
- Button: RE (Range Extender) Button, Reset Button
- Antenna: 3x Internal
- Power Consumption: About 6.5W
- Dimensions (WxDxH): 4.3 x 2.6 x 3.0 inch / 110.0 x 65.8 x 75.2 mm
- Wireless Features:
- Frequency: 2.4GHz & 5GHz
- Signal Rate:
- 5GHz: Up to 433Mbps
- 2.4GHz: Up to 300Mbps
- Reception Sensitivity:
- 2.4GHz:
- 270M: -70dBm @ 10% PER
- 130M: -70dBm @ 10% PER
- 108M: -73dBm @ 10% PER
- 54M: -75dBm @ 10% PER
- 11M: -86dBm @ 8% PER
- 6M: -92dBm @ 10% PER
- 1M: -94dBm @ 8% PER
- 5GHz:
- 390M: -60dBm @ 10% PER
- 29.3M: -83dBm @ 10% PER
- 108M: -64dBm @ 10% PER
- 13.5M: -87dBm @ 10% PER
- 78M: -68dBm @ 10% PER
- 6.5M: -90dBm @ 10% PER
- 54M: -75dBm @ 10% PER
- 6M: -90dBm @ 10% PER
- Transmit Power: < 20 dBm (EIRP)
- Wireless Modes: Range Extender
- Wireless Functions: WMM (Wi-Fi Multimedia), Wireless Statistic, Domain Login Function
- Wireless Security: 64/128/152-bit WEP, WPA-PSK / WPA2-PSK
- Others:
- Certifications: CE, FCC, RoHS
- Package Contents: AC750 WiFi Range Extender RE200, RJ-45 Ethernet Cable, Resource CD, Quick Installation Guide
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, Mac OS, NetWare, UNIX or Linux
- Environment:
- Operating Temperature: 0 C~40 C (32 F~104 F)
- Storage Temperature: -40 C~70 C (-40 F~158 F)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
Note Currently out of stock
Available Quantity 0
UPC 845973071875
SKU mingleRE200
Item TP-Link TL-SF1016D 16-Port Unmanaged 10/100Mbps Desktop Switch
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $34.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: TL-SF1016D
- Features:
- Innovative energy-efficient technology saves power up to 70%
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
- Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
- 3.2Gbps Switching Capacity
- Auto-MDI/MDIX eliminates the need for crossover cables
- Supports MAC address auto-learning and auto-aging
- Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps hardware
- Fanless design ensures quiet operation
- Desktop or wall-mounting design
- Plug and Play design simplifies installation
- Hardware:
- Standards: IEEE802.3, 802.3u, 802.3x
- Protocols: CSMA/CD
- Interface: 16x 10/100Mbps RJ45 Ports (AUTO Negotiation/AUTO MDI/MDIX)
- Mac Address Table: 1 K
- External Power Supply: 100~240VAC, 50/60Hz
- Fan Quantity: Fanless
- LEDs: Power, 1~16
- Dimensions (Wx DxH): 7.9 x 5.6 x 1.6 inch / 200.0 x 142.0 x 40.0 mm
- Software:
- Transfer Method: Store and Forward
- Advanced Functions: Green Technology, saving power up to70%; 802.3X Flow Control, Back Pressure; Auto-Uplink Every Port
- Switching:
- Half and Full Duplex
- MAC Address Learning
- 3.2Gbps Backplane Bandwidth
- Forwarding Rate:
- 10BASE-T: 14880pps/port
- 100BASE-TX: 148800pps/port
- Data Rate:
- 10/100Mbps at Half Duplex
- 20/200Mbps at Full Duplex
- Others:
- Certifications: CE, FCC, RoHS
- Package Contents: 16-Port 10/10Mbps Desktop Switch TL-SF1016D; Power Adapter; User Guide
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
- Environment:
- Operating Temperature: 0oC~40oC (32oF~104oF)
- Storage Temperature: -40oC~70oC (-40oF~158oF)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
Note Currently out of stock
Available Quantity 0
UPC 845973020293
SKU mingleTL-SF1016D
Item Case Logic QHDC-101-BLACK Portable Hard Drive Case (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $20.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: QHDC-101-BLACK
- Features:
- Compact case to store or transport smaller portable hard drives
- Slimline case protects your device on its own or in your favorite bag
- Durable, semi-rigid exterior to protect valuable data
- Interior elastic strap keeps the hard drive in place during transport
- Interior strap secures portable hard drive in place
- Internal mesh pocket conveniently stores power cords
- Zippered closure provides all-around protection
- Materials: Molded EVA Foam
- Fits Devices: 3.5 x 1.5 x 5.3 inch
- Color: Black
- Dimensions: 3.75 x 1.60 x 5.75 inch
- Weight: 0.19 lbs
Note Currently out of stock
Available Quantity 0
UPC Does not apply
SKU mingle3201253
Item Supermicro AOM-S3108-H8 Low-Profile SAS3 12Gb/s 8-port PCI-E Internal RAID Adapter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $338.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: AOM-S3108-H8
- Features:
- Designed for Blade Systems
- Supports 16 physical Devices
- Advanced array configuration and management utilities
- Automatically negotiates PCI-E link widths
- Power management support
- Supports 1.5, 3.0, 6.0 and 12.0 Gb/s SAS and SATA data transfer rates
- Port independent auto-negotiation
- Supports SSP, SMP, STP and SATA protocols
- Optional Supercap/TFM Unit for cached data protection (BTR-TFM8G-LSICVM02; Installation kit: MCP-240-00127- 0N) - Ambient operating temperature from 10 C - 55 C
- Processor: LSI SAS 3108 I/O processor
- Memory: 2GB DDR3-1866 Memory
- Connectors: 8x Internal SAS-3 12Gb/s Ports
- Interface: PCI-Express
- RAID Levels: RAID 0, 1, 5, 6, 10, 50, 60
- Compatible Motherboards: X9DRW-CF, X9DRW-CF31, X9DRW-CTF31
- Operating System Support: Windows XP/ 2K3/ 2K8/ Vista, RedHat Enterprise and SUSE Linux
- Low-profile Designed
- Dimensions (LxH): 6.0 x 3.0 inch
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042147366
SKU mingleAOM-S3108-H8
Item Supermicro AOC-USAS-L8I 3Gb/s 8 Ports SAS Internal RAID Adapter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $159.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: AOC-USAS-L8I
- Features
- LSISAS 1068E SAS controller
- 8-port (internal), 3Gb/s per port
- 1x PCI Express host interface
- Supports 122 HDD with IT mode (HBA mode-default shipping mode) / Support RAID 0,1 and 1E with IR mode
- Double the performance compare with SWR5
- 16MB onboard SRAM
- Supports MegaRAID Storage Manager Software
- Automatically negotiates PCI-E link widths
- Power management support
- Supports 1.5 and 3.0 Gb/s SAS and SATA data transfer rates
- Port independent auto-negotiation
- Supports SSP, SMP, STP and SATA protocols
- OS Support : Windows 2000/XP/2003, RedHat Enterprise and SUSE Linux
- Dimensions: 4.376 x 6.6 inch
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042019366
SKU mingleAOC-USAS-L8I
Item Supermicro AOM-SAS3-8I8E 8-port Mini SAS HD Int-to-Ext Cable Adapter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $68.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: AOM-SAS3-8I8E
- Supermicro AOM-SAS3-8I8E 8-port Mini SAS HD Int-to-Ext Cable Adapter
Note Currently out of stock
Available Quantity 0
UPC 672042162406
SKU mingleAOM-SAS3-8I8E
Item Supermicro SuperChassis CSE-515-R407 400W 1U Rackmount Server Chassis (No Paint)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $450.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CSE-515-R407
- Case Type: 1U Rackmount
- Color: No Paint
- M/B Type: Support STD and WIO Motherboard
- Processor Support: Supports Single Intel/ AMD Processors
- Drive Bays: 2x 2.5" Fixed Internal Drive Bay (w/ bracket)
- Expansion Slots: 2x Full Height Expansion Slots
- Cooling System: 4x 40x56mm PWM Fans, 2x Fans for AOC Cooling
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: 2x Network Activity, Fan Fail/System Over Heat, HDD Activity, Power Status
- Power Supply: 400W (1+1) 80 PLUS Platinum Certified Redundant Power Supply w/ PMBus and I2C
- Dimensions (WxDxH): 17.2 x 16.9 x 1.7 inch / 437.0 x 429.0 x 43.0 mm
- Gross Weight: 18.00 lbs / 8.16 kg
- Chassis and Power Supply only. Does not include MB, HD or other parts shown in pictures.
Note Currently out of stock
Available Quantity 0
UPC 672042211418
SKU mingleCSE-515-R407
Item Supermicro SuperChassis CSE-732D3-903B 900W Mid-Tower Server Chassis (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $221.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CSE-732D3-903B
- Case Type: Mid-Tower Chassis
- Color: Black
- M/B Type: ATX (12.0 x 9.6 inch), EATX (12.0 x 13.0 inch), ATX (12.0 x 10.0 inch), MicroATX (9.6 x 9.6 inch)
- Processor Support: Dual, single Intel/AMD processors
- Drive Bays:
- Peripheral: 2x 5.25" Peripheral Drive Bays
- Internal: 4x 3.5" fixed drive bay
- Expansion Slots: 7x full-height & full-length expansion slots
- Cooling System: 2x 12cm Front Cooling Fan
- Front Panel:
- Buttons: Power On/Off
- LEDs: Network Activity, HDD activity, System Information
- Power Supply: 900W 80 PLUS Gold Certified AC Multi Output Power Supply
- Dimensions (WxDxH): 16.70 x 20.68 x 7.60 inch / 424.0 x 525.0 x 193.0 mm
- Gross Weight: 30.0 lbs / 13.61 kg
- Chassis only. Does not include CPU, MB, HD, Memory or other parts shown in the photo.
Note Currently out of stock
Available Quantity 0
UPC 672042174805
SKU mingleCSE-732D3-903B
Item Supermicro SuperChassis CSE-732D4-500B 500W Mid-Tower Server Chassis (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $149.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CSE-732D4-500B
- Case Type: Mid-Tower Chassis
- Color: Black
- M/B Type: EATX (12.0 x 13.0 inch), ATX (12.0 x 10.0 inch), MicroATX (9.6 x 9.6 inch)
- Processor Support: Dual, Single Intel/AMD Processors
- Drive Bays:
- Internal: 4x 3.5" SAS/SATA HDD Bays (90 rotatable drive cage)
- Peripheral: 2x 5.25" Peripheral Drive Bays, 1x 3.5" Peripheral Drive Bay
- Expansion Slots: 7x Full-height, Full-length I/O Expansion Slots
- Cooling System: 1x 120mm (1850rpm) Rear Exhaust Fan
- Front Panel:
- Buttons: Power On/Off
- LEDs: Power Status, Hard Drive Activity, Network Activity, System Overheat
- Ports: 2x USB 3.0 Ports, 2x USB 2.0 Ports, 2x HD/AC97 Audio Ports
- Power Supply: 500W 80 PLUS Bronze Certified AC Power Supply w/ PFC
- Dimensions (WxDxH): 7.60 x 20.68 x 16.70 inch / 193.0 x 525.3 x 424.0 mm
- Weight: 30.0 lbs / 13.6 kg
- Chassis only. Does not include CPU, MB, HD, Memory or other parts shown in the photo.
Note Currently out of stock
Available Quantity 0
UPC 672042088607
SKU mingleCSE-732D4-500B
Item Supermicro SuperChassis CSE-743TQ-1200B 1200W 4U Rackmount Server Chassis (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $470.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CSE-743TQ-1200B
- Case Type: 4U Rackmount
- Color: Black
- M/B Type: EATX, ATX (12.0 x 13.0 inch)
- Processor Support: Dual, Single Intel/AMD Processors
- Drive Bays: 8x 3.5" Hot-swap SAS/SATA Drive Bays, 3x standard 5.25" Drive Bays
- Expansion Slots: 7 full-height & full-length expansion slot(s)
- Backplane: 743 SAS Backplane w/ AMI MG9072
- Cooling System: 4x 80mm PWM Chassis Middle Fans, 2x 80mm PWM Rear Chassis Fans
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: 2x Network Activity, Fan Fail/System Over Heat, HDD activity, Power Status, Unit Identification (UID)
- Ports: 2x USB 3.0 Ports
- Power Supply: PS2/ATX 1000/1200W 80 PLUS Platinum Certified Multi-output power supply, platinum level, Super quiet W/PMbus
- Dimensions (WxDxH): 7.0 x 25.5 x 17.8 inch / 178.0 x 647.0 x 452.0 mm
- Gross Weight: 53.0 lbs / 24.04 kg
- Chassis Only. CPU, MB, HD, memory and other parts are not included.
Note Currently out of stock
Available Quantity 0
UPC 672042096022
SKU mingleCSE-743TQ-1200B
Item Supermicro SuperChassis CSE-813MTQ-R400CB 400W 1U Rackmount Server Chassis (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $493.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: CSE-813MTQ-R400CB
- Case Type: 1U Rackmount
- Color: Black
- M/B Type: MicroATX (9.6" x 9.6"), ATX (12" x 10")
- Processor Support: Dual, single Intel / AMD processors
- Drive Bays: 4x 3.5" Hot-swap SAS2 / SATA drive bays
- Peripheral Drives: Optional Slim DVD-ROM drive; Front USB/COM access
- Expansion Slots: 1x full-height AOC expansion slot
- Backplane: 1x SAS / SATA backplane
- Cooling System: 4x 4cm 4-pin PWM fans
- Power Supply: 400W (1+1) Redundant Short Depth AC-DC high-efficiency power supply w/ PMBus and I2C
- Dimensions (WxDxH): 17.2 x 19.85 x 1.7 inch / 437.0 x 504.2 x 43.0 mm
- Weight: 33.5 lbs / 15.2 kg
- Chassis only. Does not including CPU, MB, HD, memory or other components.
Note Currently out of stock
Available Quantity 0
UPC 672042085279
SKU mingleCSE-813MTQ-R400CB
Item Supermicro AOC-SGP-I2 2-Port Gigabit Ethernet Adapter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $104.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: AOC-SGP-I2
- Features:
- Low-Profile Standard Form Factor in 3.9-inch in Length
- PCI Express 2.1 (2.5GT/s or 5GT/s)
- Two RJ-45 ports
- Intel I/O Acceleration Technology (I/O AT) supported
- Support of VMDq, Next-Generation VMDq, and PC-SIG SR-IOV for Virtualized Environments
- Jumbo Frame Support of up to 9.5KB
- IEEE 802.3az - Energy Efficient Ethernet (EEE)
- Low Power Consumption (5W Typical)
- iSCSI Remote Boot support
- Flexible I/O Virtualization and Quality of Service (QoS)
- PXE Boot Support
- RoHS compliant 6/6
- General:
- Intel i350 GbE controller
- Compact size low-profile standard form factor
- PCI-E 2.1 x4 (2.5GT/s or 5GT/s) interface
- Dual RJ-45 connectors
- Intel PROSet Utility for Windows Device Manager
- Intel I/O Acceleration Technology (I/O AT)
- Power Consumption: about 4W
- Ethernet Features:
- IEEE 802.3 auto-negotiation for speed, duplex, and flow control
- IEEE 802.3x and 802.3z compliant flow control support
- Automatic cross-over detection function (MDI/MDI-X)
- 1Gb/s Ethernet IEEE 802.3, 802.3u, 802.3ab PHY specifications compliant
- IEEE 1588 protocol and 802.1AS implementation
- Power Management and Efficiency:
- IEEE 802.3az - Energy Efficient Ethernet (EEE) which reduces power consumption of the PHY by about 50%
- DMA Coalescing reduces platform power consumption
- Active State Power Management (ASPM) support
- LAN disable function
- MAC Power Management controls
- Low Power Link Up - Link Speed Control
- Maximum Power Consumption: 4W
- Virtualization Features:
- VM to VM Packet forwarding (Packet Loopback)
- Eight TX and RX queue pairs per port to support VMWare NetQueue and Microsoft VMQ
- Flexible Port Partitioning: 32 Virtual Functions
- PC-SIG SR-IOV implementation
- IEEE 802.1q VLAN support
- IEEE 802.1q advanced packet filtering
- Performance Features:
- TCP/UDP, IPv4 and IPv6 checksum offloads to improve CPU usage
- Low Latency Interrupts
- Tx TCP segmentation offload (IPv4, IPv6) increases throughput and lowers processor usage
- Receive Side Scaling (RSS) for Windows environment, Scalable I/O for Linux environments
- Jumbo Frames support up to 9.5K Bytes
- Intelligent interrupt generation
- OS Support:
- Windows XP SP3, Vista SP2, 7 SP1 2003 SP2, 2008 SP2, 2008 R2S
- RedHat EL 5.5, 6.0; SuSe SLES 10 SP3, 11 SP1
- FreeBSD 8.0
- VMware ESX 4.0, 4.1, 5.0
- Xen
- Cables Support: RJ-45 Category-5/5e up to 100m
- Supported Platforms:
- Motherboards with minimum PCI-E x4 slot
- Server Systems with low-profile or full-height PCI-E x4 expansion slot
- Dimensions:
- Card PCB (LxH): 3.90 x 2.73 inch / 9.91 x 6.90 cm
- Height of End Brackets: Standard - 4.725 inch / 12.000 cm; Low-profile - 3.130 inch / 7.940 cm
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042131945
SKU mingleAOC-SGP-I2
Item Supermicro CBL-0062L 8pin Power Extension Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $13.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: CBL-0062L
- 12V Power Connector Extension Cable, 8-pin to 8-pin, 20cm, Pb-free
Note Currently out of stock
Available Quantity 0
UPC 672042051380
SKU mingleCBL-0062L
Item Supermicro CBL-0481L 81cm SATA to SATA Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $6.20
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CBL-0481L
- Features:
- Copper Cable Assembly
- Perfect for SATA Flat Straight-Straight Cable Applications
- Also Available in 29cm and 55cm
- Supermicro Certified
- Cable Type: SATA Cables
- Connector: SATA
- Connector (Other Side): SATA
- Cable Length: 81 cm
- RoHS and REACH Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042112142
SKU mingleCBL-0481L
Item Supermicro CBL-PWEX-0663 PCIe 8 pin male (black) to CPU 8 pin female (white) power adapter, 5cm, 18AWG, 1 cable per passive GPU
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $15.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CBL-PWEX-0663
- Supermicro CBL-PWEX-0663 PCIe 8 pin male (black) to CPU 8 pin female (white) power adapter, 5cm, 18AWG, 1 cable per passive GPU
Note Currently out of stock
Available Quantity 0
UPC 672042178728
SKU mingleCBL-PWEX-0663
Item Supermicro CBL-SAST-0671 Cable
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $37.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CBL-SAST-0671
- CBL-SAST-0671 SAS Cable
Note Currently out of stock
Available Quantity 0
UPC 672042172962
SKU mingleCBL-SAST-0671
Item Supermicro CBL-SAST-0591 75cm Cross-over Mini SAS HD to 4x SATA Internal Cable w/ SB
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $14.80
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: CBL-SAST-0591
- Features:
- Cross-over mini SAS HD to 4 SATA w/SB, S. 75cm. 30AWG, HF, RoHS/REACH, PBF
- Connector Type: Mini-SAS HD Connector, 4x SATA Connectors
- Cable Length: 75.0 cm
Note Currently out of stock
Available Quantity 0
UPC 672042150090
SKU mingleCBL-SAST-0591
Item Supermicro CDM-SATA Mini SATA to SATA Adapter for Slim DVD
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $24.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CDM-SATA
- Supermicro CDM-SATA Mini SATA to SATA Adapter for Slim DVD
Note Currently out of stock
Available Quantity 0
UPC 672042043736
SKU mingleCDM-SATA
Item Supermicro CDM-USATA-G Mini SATA to USB Adapter for Slim DVD
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $14.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CDM-USATA-G
- Supermicro CDM-USATA-G Mini SATA to USB Adapter for Slim DVD
Note Currently out of stock
Available Quantity 0
UPC 672042052394
SKU mingleCDM-USATA-G
Item Supermicro DVM-PLDS-DVDRW-SBT5 Philips Slim Black DVD-RW SATA Drive
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $52.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: DVM-PLDS-DVDRW-SBT5
- Supermicro DVM-PLDS-DVDRW-SBT5 Philips Slim Black DVD-RW SATA Drive, RoHS
Note Currently out of stock
Available Quantity 0
UPC 672042182992
SKU mingleDVM-PLDS-DVDRW-SBT5
Item Supermicro FAN-0087L4 40x40x56mm 4Pin PWM Fan for 1U SC512F/SC811 Chassis
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $30.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: FAN-0087L4
- Application: SC512F, SC811 Chassis
- Rated Current: 0.7 A
- Fan Speed: 12,000 / 8,900 RPM
- Air Flow: 23.0 CFM
- Static Pressure: 1.2 inch H2O
- Noise: 56.0 dBA
- Connectors: 4 Pin
- Dimensions (WxLxH): 40.0 x 40.0 x 56.0 mm
Note Currently out of stock
Available Quantity 0
UPC 672042023158
SKU mingleFAN-0087L4
Item Supermicro MCP-220-00001-01 4th generation 3.5" Hot-swap Hard Drive Tray (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $28.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: MCP-220-00001-01
- Supermicro MCP-220-00001-01 Accessory Black 4th generation 3.5" Hot-swap Hard Drive Trays
Note Currently out of stock
Available Quantity 0
UPC 672042008797
SKU mingleMCP-220-00001-01
Item Supermicro MCP-220-93707-0B Black Hotswap Gen 7 2.5 to 3.5 HDD Tray for SC937 SBB w/ LSI Interposer bkt (SATA HDD to SAS)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-220-93707-0B
- Supermicro MCP-220-93707-0B Black Hotswap Gen 7 2.5 to 3.5 HDD Tray for SC937 SBB with LSI interposer bkt (SATA HDD to SAS)
Note Currently out of stock
Available Quantity 0
UPC 672042088669
SKU mingleMCP-220-93707-0B
Item Supermicro MCP-290-00057-0N 26.5" to 36.4" Mounting Rail Set for 4U 17.2" W
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $86.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-290-00057-0N
- Compatibility: Supermicro 846E1-R710B SuperChassis
- Supermicro MCP-290-00057-0N 26.5" to 36.4" Mounting Rail Set, Quick Release for 4U 17.2" W (for Rev. K4 or later)
Note Currently out of stock
Available Quantity 0
UPC 672042052769
SKU mingleMCP-290-00057-0N
Item Supermicro MCP-260-00070-0N Standard I/O Shield for X10SLV with EMI Gasket
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $6.80
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-260-00070-0N
- Supermicro MCP-260-00070-0N Standard I/O Shield for X10SLV with EMI Gasket
Note Currently out of stock
Available Quantity 0
UPC 672042141517
SKU mingleMCP-260-00070-0N
Item Supermicro MCP-260-00063-0N Standard I/O Shield for X10SLQ
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $8.10
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-260-00063-0N
- Supermicro MCP-260-00063-0N Standard I/O Shield for X10SLQ
Note Currently out of stock
Available Quantity 0
UPC 672042135066
SKU mingleMCP-260-00063-0N
Item Supermicro MCP-220-82502-0B Fixed HDD Tray
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $16.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-220-82502-0B
- Supermicro Fixed HDD tray or FDD dummy tray (Black)
Note Currently out of stock
Available Quantity 0
UPC 672042023417
SKU mingleMCP-220-82502-0B
Item Supermicro MCP-290-00050-0N Rail Set for 1U 16.8W SC111
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $38.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-290-00050-0N
- Inner Rail: Quick-Release
- Outer Rail: Screw-Type
- Compatibility: 1U SC111 Series Chassis
- Supermicro MCP-290-00050-0N Rail Set, Quick/Screw, for 1U 16.8 W SC111
Note Currently out of stock
Available Quantity 0
UPC 672042081783
SKU mingleMCP-290-00050-0N
Item Supermicro MCP-290-00056-ON 1U Short Outer Rail Set-Quick for 1U 17.2" W Chassis
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $42.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: MCP-290-00056-ON
- 19" to 26.4"(Square hole) Short Outer Rail, quick for 1U 17.2" W chassis
- Compliant to SC512F, 515, 813, 813M, 814, 815, 816, 818, 819, 808, 809, 113, 113M Series Chassis
Note Currently out of stock
Available Quantity 0
UPC 672042035205
SKU mingleMCP-290-00056-0N
Item Supermicro MCP-640-00068-0N Battery Holder Bracket for LSI00279 IBBU09 BATTERY BACKUP
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $43.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: MCP-640-00068-0N
- Supermicro MCP-640-00068-0N Battery Holder Bracket for LSI00279 IBBU09 BATTERY BACKUP
Note Currently out of stock
Available Quantity 0
UPC 672042116959
SKU mingleMCP-640-00068-0N
Item Supermicro MCP-310-81301-0B Air Shroud for SC813M
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $9.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: MCP-310-81301-0B
- Supermicro MCP-310-81301-0B Air Shroud for SC813M (AMD AM2, FAN-0061)
Note Currently out of stock
Available Quantity 0
UPC 672042015146
SKU mingleMCP-310-81301-0B
Item Supermicro CSE-PT8L 1U Rackmounting Rail Kit
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $37.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CSE-PT8L
- 1U Rackmounting Rail Kit
Note Currently out of stock
Available Quantity 0
UPC 672042666898
SKU mingleCSE-PT8L
Item Supermicro CSE-PT84L 2.5 inch Hard Drisk Assembly
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $8.40
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CSE-PT84L
- Supermicro CSE-PT84L 2.5" Hard Drisk Assembly, PB Free
Note Currently out of stock
Available Quantity 0
UPC 672042003303
SKU mingleCSE-PT84L
Item Supermicro RSC-R1U-33 1U PCI Riser Card
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: RSC-R1U-33
- Supermicro RSC-R1U-336 1U 3.3V PCI Riser Card
Note Currently out of stock
Available Quantity 0
UPC 672042136131
SKU mingleRSC-R1U-33
Item Supermicro RSC-R2UU-2E8R 2U Right Slot PCI-Express x8 + UIO Riser Card
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: RSC-R2UU-2E8R
- Motherboard Slot Type: UIO Slot
- Output Type: 2x PCI-Express x8 Slots
- Form Factor: 2U
- Position: Right Slot
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042013418
SKU mingleRSC-R2UU-2E8R
Item Supermicro SNK-V0026L-TP2
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $25.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: SNK-V0026L-TP2
- Supermicro SNK-V0026L-TP2
Note Currently out of stock
Available Quantity 0
UPC 672042068265
SKU mingleSNK-V0026L-TP2
Item Supermicro SNK-P0057PS 1U High Performance Passive CPU Heat Sink for X9, X10 UP/DP/MP Systems Equipped w/ a Narrow ILM MB
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $35.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: SNK-P0057PS
- Form Factor: 1U Passive, UP, DP, MP
- Socket Type: LGA 2011 (Narrow ILM)
- CPU Support: Intel Xeon Processor E5-2600, E5-2600 v2, E5-2600 v3 and E5-4600 Series
- Major Integrated Part: Copper + Aluminum Base, Copper Fins, Heat Pipes
- Mounting Method: Screws and Springs
- Dimensions (WxLxH): 80.0 x 104.0 x 26.0 mm
- Supermicro SNK-P0057PS 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB
Note Currently out of stock
Available Quantity 0
UPC 672042158768
SKU mingleSNK-P0057PS
Item Supermicro AOC-TBT-DSL5320 Thunderbolt 2 Add-on Card
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $144.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: AOC-TBT-DSL5320
- Form Factor: Single slot (3.71" length x 2.99" height) with full height bracket
- Chipset: DSL5320 Thunderbolt 2 controller (Falcon Ridge)
- Thunderbolt Connector: 1
- DisplayPort Connector: 1
- DisplayPort Revision: 1.2
- PCIe Connection: PCIe 2.0 x4 from PCH PCIe slot
- GPIO Connector: Needs GPIO cable to TBT GPIO header on MB (Supported on X10DAi/C/X, X10DAL and X10DRG-Q)
- Thunderbolt Bandwidth: 20 Gbps
- TBT AIC Power Consumption: 4.1W max
Note Currently out of stock
Available Quantity 0
UPC 672042172399
SKU mingleAOC-TBT-DSL5320
Item Supermicro AOC-USAS2LP-H8IR OPEN Low Profile SAS 6Gb/s Eight-Port Internal RAID Adapter
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $407.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: AOC-USAS2LP-H8IR OPEN
- Features:
- Broadcom 2108 8-port PCI-E SAS-2 controller
- 8-port (8 internal) 6Gb/s per port
- Supports RAID 0, 1, 5, 6, 10, 50, 60
- On board hardware IO Processor
- 512MB 800MHz DDR2 on-card cache
- Advanced array configuration and management utilities
- Automatically negotiates PCI-E link widths
- Power management support
- Supports 1.5, 3.0 and 6.0 Gb/s SAS and SATA data transfer rates
- Port independent auto-negotiation
- Optional Battery Backup Unit for cached data protection (BTR-0018L-0000-LSI) - operating temperature (Ambient) from 10C - 45C
- Supports SSP, SMP, STP and SATA protocols
- Compatible UIO Motherboards and Servers: Motherboards - H8DGU-LN4F+, H8DGU-F, X8DTN+(-F), X8DTU(-F)
- OS Support: Windows XP/2003/2008/Vista, RedHat Enterprise and SUSE Linux
- Dimensions (LxH): 6.60 x 2.71 inch
- Low-profile Designed
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC Does not apply
SKU mingleAOC-USAS2LP-H8IR OPEN
Item Supermicro FAN-0154L4 40x40x28mm 22.5K RPM Middle Cooling Fan for SC813MF Chassis
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $20.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: FAN-0154L4
- Compatibility: SC813MF Chassis
- Rated Current: 1.05 A
- Fan Speed: 22,500 RPM
- Air Flow: 28.6 CFM
- Static Pressure: 3.46 in.H2O
- Noise: 61.0 dBA
- Dimensions (WxLxH): 40.0 x 40.0 x 28.0 mm
Note Currently out of stock
Available Quantity 0
UPC 672042163298
SKU mingleFAN-0154L4
Item Supermicro PDB-PT748-8824 4U 24pin Redundant Power Distributor w/ Output Connectors
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $122.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: PDB-PT748-8824
- Supermicro PDB-PT748-8824 4U 24pin Redundant Power Distributor w/ Output Connectors
Note Currently out of stock
Available Quantity 0
UPC 672042003181
SKU minglePDB-PT748-8824
Item Supermicro PWS-1K02A-1R 1000W 80 PLUS Titanium Power Supply w/ Digital Switching Control
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $210.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: PWS-1K02A-1R
- Type: 1000W 80 PLUS Titanium Level (96%) High-efficiency Redundant Single Output Power Supply
- Total Power: 1000 W
- Input
- Voltage: 100 - 127V/200 - 240V
- Frequency Range: 50/60Hz
- Output: +12V DC @ 62.5A (100 - 127V), +12V DC @ 83A (200 - 240V), +12VSB DC @ 2.1A
Note Currently out of stock
Available Quantity 0
UPC 672042154951
SKU minglePWS-1K02A-1R
Item Supermicro PWS-1K21P-1R 1200W High-Efficiency (1+1) Redundant Power Supply with PMBus
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $215.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: PWS-1K21P-1R
- 1200W high-efficiency (1+1) redundant
- Type: 1U
- Input Voltage: 100~240V, 50~60Hz, 5~8 Amp
- 80 PLUS Gold Certified(Gold Level 93%)
Note Currently out of stock
Available Quantity 0
UPC 672042041862
SKU minglePWS-1K21P-1R
Item Supermicro PWS-703P-1R 700W 80 PLUS Gold 1U Power Supply Module w/ PMBus
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $165.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: PWS-703P-1R
- Type: Module
- Total Power: 700 W
- Output: +12V @ 58/62A, +5V Standby @ 3A
- PFC: Yes
- PM Bus: Yes
- Form Factor: 1U
- Certification: 80 PLUS Gold Certified
- Dimensions (WxLxH): 50.0 x 320.0 x 40.0 mm
Note Currently out of stock
Available Quantity 0
UPC 672042059980
SKU minglePWS-703P-1R
Item Supermicro PWS-721P-1R 720W 1U 80 Plus Gold Redundant Module Type Power Supply w/ PFC & PM Bus
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $163.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: PWS-721P-1R
- Total Power Output: 720W
- Type: Module
- Form Factor: 1U
- Output: +12V @ 59A, +5V Standby @ 4A
- Input:
- Voltage Range: 100-240V
- Frequency Range: 50-60Hz
- Current Range: 9-4A
- Output Type: Gold Finger (19 Pair Connector)
- PFC: Yes
- PM Bus: Yes
- 80 Plus Certification: 80 Plus Gold
- Dimensions (WxLxH): 76.0 x 346.0 x 40.0 mm
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042041909
SKU minglePWS-721P-1R
Item Supermicro PWS-920P-SQ 920W 1U Power Supply Module w/ PFC & PM Bus & Backplane
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $200.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: PWS-920P-SQ
- Type: Module
- Application: 1U Chassis
- Output Power: 920 W
- Output: +12V @ 75A, +5V Standby @ 4A
- PFC: Yes
- PM Bus: Yes
- Backplane: Yes
- Certification: 80 PLUS Platinum
- Dimensions (WxLxH): 76.0 x 360.0 x 40.0 mm
Note Currently out of stock
Available Quantity 0
UPC 672042077205
SKU minglePWS-920P-SQ
Item Supermicro SuperServer SYS-1026GT-TRF Dual LGA1366 1800W 1U Rackmount Server Barebone System (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $1685.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications
- Mfr Part Number: SYS-1026GT-TRF
- Motherboard: X8DTG-QF+
- Processor: Dual LGA1366
- Support Intel 64-bit Xeon X5600/E5600/L5600 Series Processors (Westmere), 40W - 130W
- Support Intel 64-bit Xeon X5500/E5500/L5500 Series Processors (Nehalem-EP), 38W - 95W
- QPI up to 6.4 GT/s
- Chipset: North Bridge Intel 5520 (Tylersburg) & South Bridge PLX 8647 + ICH10R
- Memory: 6x 240pin DDR3-1333/1066/800 DIMM Slots, Supports up to 96GB ECC/REG Memory
- Slots: 4x PCI-Express 2.0 x16 Slots (one runs at x8 & is a low-profile slot via riser card)
- SATA: 6x SATA2 Ports, Supports RAID 0, 1, 5, 10
- Video: Matrox G200eW Graphics w/ 16 MB DDR2 Video Memory
- LAN: Intel 82576 Dual-Port Gigabit Ethernet Controller; 1x Realtek RTL8201N PHY (dedicated IPMI)
- Drive Bays: 4x 2.5" SATA Hot-swap Drive Trays
- Backplane: SAS / SATA HDD Backplane (SAS support requires optional SAS controller)
- Ports: 2x USB 2.0 Ports, 1x VGA Port, 1x Serial Port, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
- Form Factor: 1U Rackmount
- Power Supply: 1800W 80 Plus Platinum Certified (1+1) Redundant Power Supply w/ PMBus
- System Cooling: 10x 4cm Heavy-duty Counter-rotating Fans w/ Optimal Fan Speed Control
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: Power, HDD Activity, 2x Network Activity, System Overheat/ Fan Fail/ UID
- Color: Black
- Dimensions (WxDxH): 17.2 x 30.6 x 1.7 inch / 437.0 x 777.0 x 43.0 mm
- Gross Weight: 37.0 lbs / 16.78 kg
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042090556
SKU mingleSYS-1026GT-TRF
Item Supermicro SuperServer SYS-1028R-MCT Dual LGA2011 600W 1U Rackmount Server Barebone System (Black)
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $1085.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: SYS-1028R-MCT
- Motherboard: Super X10DRL-CT
- Processor: Dual LGA2011
- Support Intel Xeon E5-2600 v3 Family Processors
- Support up to 18 Cores
- Cache up to 45MB
- QPI up to 9.6 GT/s
- Support up to 145W TDP
- Chipset: Intel C612 Express
- Memory: 8x 288pin DDR4-2133/ 1866/ 1600 DIMM Slots, Supports up to 512GB ECC/Load Reduced Memory or up to 256GB ECC/REG Memory
- Slots: 1x PCI-Express 3.0 x8 Slot (Full-height, Half-length)
- SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10
- SAS: 8x SAS3 Ports, Support RAID 0, 1, 5, 6, 10, 50, 60
- Video: Aspeed AST2400 BMC Graphic
- LAN: Intel X540 10Gb Gigabit Ethernet Controller, Intel i210 Gigabit Ethernet Controller, 1x Realtek RTL8211E PHY (dedicated IPMI)
- Drive Bays: 8x 2.5" Hot-swap SAS/SATA HDD trays
- Backplane: SATA/SAS HDD Backplane
- Ports: 2x USB 3.0 ports (via header), 3x USB 2.0 ports (2 via header, 1 Type A), 1x VGA Port, 2x RJ45 LAN Ports, 2x RJ45 10GBase-T LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
- Form Factor: 1U Rackmount
- Power Supply: 600W 80 PLUS Platinum Certified AC power supply w/ PFC (24-pin)
- System Cooling: 4x 4cm high performance PWM fans with optimal fan speed control
- Front Panel:
- Buttons: Power On/Off, System Reset, UID
- LEDs: Power Status, HDD Activity, 2x Network Activity, Universal Information (UID)
- Color: Black
- Dimensions (WxDxH): 17.20 x 19.98 x 1.70 inch / 437.0 x 508.0 x 43.0 mm
- Gross Weight: 38.0 lbs / 17.24 kg
- RoHS Compliant
Note Currently out of stock
Available Quantity 0
UPC 672042176571
SKU mingleSYS-1028R-MCT
Item VCOM CG571B-15FEET 15ft HDMI Type A Male to HDMI Type A Male Cable w/ HDMI v1.4
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $13.00
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description Specifications - Mfr Part Number: CG571B-15FEET
- Features:
- High-speed HDMI cable significantly improves the performance of your home entertainment systems
- Efficient design premium transfer of both audio and video outputs in Full HD
- HDCP compliant, offering greater versatility
- Full HD HDMI cable supports 1080p/ Ethernet/ 3D/ 4k x 2k resolutions
- 24K gold-plated, metal shell connectors
- Nylon net jacket
- Connector Type: HDMI v1.4 Type A Male Connector (Gold Plated with Pure Copper)
- Cable Length: 15.0 ft
Note Currently out of stock
Available Quantity 0
UPC 840273101239
SKU mingleCG571B-15FEET
Item VCOM CE001-6FEET 6ft AC Extension Power Cord
|
Show more images
|
Please note, Login or Registration at time of checkout will be required. Thank you.
|
Price $7.50
Expand to see more details...
Rebate 15% of item price after purchase. Details to redeem rebate will be provided in shipment
Shipping Free 2 day shipping
Return Policy 6 months free return. Return item within the time specified.
Product Description
Specifications
-
Mfr Part Number: CE001-6FEET
-
Features:
-
ICE AC extension power cord, 6feet, UL standard
-
The whole wire is produced based on standard, meeting up with safety standard, safe and reliable
-
With first class workmanship, conductor adopts oxygen-free copper, ensuring low resistance and loss
-
Standard US plug, ensuring durability and lifetime
-
Coat is made up of PVC with high quality, durable and wear-resisting
-
Fully surrounded plug makes your life more safe
-
Connector Type: IEC AC Extension Power Connector
-
Cable Length: 6.0 ft
Note Currently out of stock
Available Quantity 0
UPC 840273101079
SKU mingleCE001-6FEET
|
